Sony STR-DN1060 - MB-1409 Board (13;18) Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
145
* C7331 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7332 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7333 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7334 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7335 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7336 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7337 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7338 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7339 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7340 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7341 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7351 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7401 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7402 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7403 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7404 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7405 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7406 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7407 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7408 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7409 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7410 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7411 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7412 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7413 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7414 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7415 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7416 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7417 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7418 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7440 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7441 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7442 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7443 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7444 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7445 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7446 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7447 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7448 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7449 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7450 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7451 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7452 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7453 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7454 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7455 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7456 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7457 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7458 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7483 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7485 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C7490
1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7491 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7492 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7493 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7494 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C7495 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C8001 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C8002 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C8003 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
* C8004 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C8005 1-165-492-21 ELECT CHIP 100uF 20% 10V
* C8008 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C8009 1-124-779-00 ELECT CHIP 10uF 20% 16V
* C8010 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C8011 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C8012 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C8013 1-164-878-11 CERAMIC CHIP 150PF 5% 50V
C8014 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C8015 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
* C8016 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C8017 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C8018 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C8020 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C8021 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN301 1-794-032-21 PIN, CONNECTOR (PC BOARD) 11P
CN401 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN501 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD) 5P
CN502 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD) 5P
CN3003 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN3004 1-794-341-51 CONNECTOR, FFC/FPC 27P
CN3500 1-764-177-11 PIN, CONNECTOR (SMD) (1.5MM) 7P (DN1060)
* CN3501 1-842-680-11 HDMI CONNECTOR (DN1060)
CN3502 1-821-398-41 HDMI CONNECTOR
(HDMI 4K SA-CD/CD IN (for AUDIO))
CN3503 1-821-398-41 HDMI CONNECTOR
(HDMI 4K BD/DVD IN (for AUDIO))
CN3504 1-821-398-41 HDMI CONNECTOR (HDMI 4K GAME IN)
CN3505 1-821-398-41 HDMI CONNECTOR
(HDMI 4K VIDEO IN) (DN860) /
(HDMI 4K VIDEO 1 IN) (DN1060)
CN3506 1-821-398-41 HDMI CONNECTOR
(HDMI 4K OUT B/ HDMI ZONE) (DN1060)
CN5001 1-821-398-41 HDMI CONNECTOR
(HDMI 4K (MHL) SAT/CATV IN DC5V 1A MAX
HDCP 2.2)
CN5012 1-821-398-41 HDMI CONNECTOR
(HDMI 4K TV OUT ARC HDCP 2.2) (DN860) /
(HDMI 4K (TV) OUT A ARC HDCP 2.2) (DN1060)
CN6500 1-785-466-51 CONNECTOR, FFC/FPC 7P
CN7000 1-785-466-51 CONNECTOR, FFC/FPC 7P
CN8000 1-843-889-11 PIN, CONNECTOR (PC BOARD) 13P
CN8001 1-820-117-51 CONNECTOR, FFC/FPC 19P
CN8002 1-820-840-31 CONNECTOR, FFC/FPC (LIF) 22P
< DIODE >
D501 6-500-514-01 DIODE BAV70
D3000 6-503-759-01 DI RB751V40, 115
D3001 6-503-738-01 DI CES521
D3002 6-503-738-01 DI CES521
D3003 6-500-514-01 DIODE BAV70
D3004 6-502-961-01 DI DA2J10100L
D3005 6-500-514-01 DIODE BAV70
D3007 6-502-961-01 DI DA2J10100L
D3190 6-502-961-01 DI DA2J10100L (DN1060)
D3191 6-502-961-01 DI DA2J10100L
D3192 6-502-961-01 DI DA2J10100L
D3801 6-503-856-01 DI PMEG3010EJ
D3811 6-503-738-01 DI CES521
D5276 6-502-961-01 DI DA2J10100L (DN1060)
MB-1409
