Sony STR-DN1060 - MB-1409 Board (14;18) Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
146
D6001 6-503-738-01 DI CES521
D6002 6-503-738-01 DI CES521
D6003 6-502-961-01 DI DA2J10100L
D6006 6-503-579-01 DI RB521SM-30GJT2R (DN1060)
D6007 6-503-579-01 DI RB521SM-30GJT2R
D6009 6-503-579-01 DI RB521SM-30GJT2R
D6010 6-503-579-01 DI RB521SM-30GJT2R
< EARTH TERMINAL >
ET300 1-780-945-11 TERMINAL, CONTACT
ET301 1-780-945-11 TERMINAL, CONTACT
ET302 1-780-945-11 TERMINAL, CONTACT
ET303 1-780-945-11 TERMINAL, CONTACT
ET304 1-780-945-11 TERMINAL, CONTACT
ET305 1-780-945-11 TERMINAL, CONTACT
< FERRITE BEAD >
FB401 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3000 1-400-862-11 BEAD, FERRITE
FB3500 1-481-348-21 EMI FERRITE (SMD) (1608) (DN1060)
FB3520 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3730 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3810 1-414-772-11 FERRITE. EMI (SMD) (2012)
FB3812 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3824 1-481-464-11 BEAD, FERRITE (1608)
FB3825 1-400-862-11 BEAD, FERRITE
FB5000 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5002 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5004 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5006 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5008 1-481-348-21 EMI FERRITE (SMD) (1608)
FB5010 1-481-348-21 EMI FERRITE (SMD) (1608)
FB6000 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB6001 1-400-862-11 BEAD, FERRITE
FB6003 1-500-445-21 FERRITE, EMI (SMD) (2012)
FB6004 1-400-862-11 BEAD, FERRITE
FB6005 1-400-862-11 BEAD, FERRITE
FB6006 1-469-125-21 FERRITE, EMI (SMD) (1608)
FB6007 1-400-862-11 BEAD, FERRITE
FB6009 1-400-862-11 BEAD, FERRITE
FB6010 1-400-862-11 BEAD, FERRITE (DN1060)
FB6011 1-400-862-11 BEAD, FERRITE
FB6012 1-400-862-11 BEAD, FERRITE
FB6500 1-400-862-11 BEAD, FERRITE
FB6501 1-400-862-11 BEAD, FERRITE
FB7000 1-414-772-11 FERRITE. EMI (SMD) (2012)
FB7200 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7207 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7300 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7301 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7302 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7303 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7304 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7305 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB7400 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB8000 1-400-862-11 BEAD, FERRITE
FB8001 1-400-862-11 BEAD, FERRITE
FB8002 1-400-862-11 BEAD, FERRITE
< IC >
IC101 (Not supplied) IC CXD90028GB-B (EXCEPT TW)
IC101 (Not supplied) IC CXD90028GB-C (TW)
IC102 (Not supplied) IC H5TQ2G63FFR-PBCR
IC103 (Not supplied) IC H5TQ2G63FFR-PBCR
IC110 (Not supplied) IC MFI337S3959
IC301 (Not supplied) IC BD00IC0WHFV-GTR
IC302 6-717-441-01 IC BD00GA5WEFJ-E2
IC305 6-718-379-01 IC RP108J081D-FE
IC306 6-718-379-01 IC RP108J081D-FE
IC307 (Not supplied) IC BD00IC0WHFV-GTR
IC308 (Not supplied) IC BD00IC0WHFV-GTR
IC309 (Not supplied) IC BD00IC0WHFV-GTR
IC310 (Not supplied) IC BD00IC0WHFV-GTR
IC313 (Not supplied) IC BD00IC0WHFV-GTR
IC314 6-718-379-01 IC RP108J081D-FE
IC315 6-718-379-01 IC RP108J081D-FE
IC318 6-717-006-01 IC BD00HC5WEFJ-E2
IC319 6-717-006-01 IC BD00HC5WEFJ-E2
IC320 6-718-379-01 IC RP108J081D-FE
IC401 6-709-888-01 IC TC7WHU04FK
IC503 6-715-164-01 IC TPS2553DBVR
IC504 6-720-030-01 IC TPS2065CDBVR
IC2001 (Not supplied) IC S34ML04G200TFI003
IC3000 6-720-177-01 IC BR24T64FJ-WE2
IC3001 6-719-856-01 IC BU4229F-TR
IC3002 A-2074-361-A IC MB9BF129TPMC-GE1 (for SERVICE)
(DN1060)
IC3002 A-2074-367-A IC MB9BF129TPMC-GE1 (for SERVICE) (DN860)
IC3190 8-759-675-54 IC TC7W53FK (TE85R) (DN1060)
IC3191 6-717-441-01 IC BD00GA5WEFJ-E2
IC3500 6-715-164-01 IC TPS2553DBVR (DN1060)
IC3510 6-717-006-01 IC BD00HC5WEFJ-E2 (DN1060)
IC3700 6-718-773-01 IC SII9575CTUC (DN1060)
IC3700 (Not supplied) IC SII9573CTUC (DN860)
IC3800 6-719-139-01 IC MM3411A50NRE
IC3810 6-718-999-01 IC MM1839A50NRE (DN1060)
IC3821 6-716-410-01 IC TMDS261BPAGR
IC3825 8-759-596-39 IC SN74LV4052APWR
IC3826 6-709-888-01 IC TC7WHU04FK
IC5000 A-2074-363-A IC W25X20CLSNIG (for SERVICE)
IC5001 6-721-481-01 IC SII9679CNUC
IC5009 A-2074-364-A IC W25X20CLSNIG (for SERVICE)
IC5010 (Not supplied) IC SII9678CNUC
IC5014 6-718-999-01 IC MM1839A50NRE
IC5018 6-715-713-01 IC TC7MBL3257CFK (TBEL)
IC5020 6-717-006-01 IC BD00HC5WEFJ-E2
IC5021 6-715-164-01 IC TPS2553DBVR
IC6000 (Not supplied) IC PCM1681GPWPR (DN1060)
IC6000 6-720-530-01 IC PCM1681PWPR (DN860)
IC6001 6-709-888-01 IC TC7WHU04FK
IC6002 6-717-987-11 IC LC89075WA-H
IC6003 8-759-680-48 IC TC7WH157FK
IC6004 6-718-383-01 IC TC74VHC393FT (ELK)
IC6005 8-759-680-48 IC TC7WH157FK
IC6006 6-715-699-01 IC CS230002-CZZR (DN1060)
IC6007 6-711-971-01 IC SRC4190IDBR
IC6008 6-707-870-01 IC TC74VHC157FT (EK)
IC6009 6-707-870-01 IC TC74VHC157FT (EK)
IC6010 6-718-999-01 IC MM1839A50NRE
MB-1409
Note: IC101, IC102, IC103, IC110, IC301, IC307, IC308, IC309,
IC310, IC313, IC2001, IC3700 (DN860), IC5010 and
IC6000 (DN1060) on the MB-1409 board cannot exchange
with single. When these parts on the MB-1409 board are
damaged, exchange the entire mounted board.
