Sony STR-DN1060 - MB-1409 Board (15;18) Components

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
147
IC6500 6-721-709-01 IC W9864G6KH-6-ER10
IC6501 (Not supplied) IC ADSST-AVR-3046
IC6502 A-2074-362-A IC W25Q16DVSSIG (for SERVICE)
IC7100 (Not supplied) IC ADV8003KBCZ-8B
IC7400 (Not supplied) IC W971GG6KB-18-ER25
IC7440 (Not supplied) IC W971GG6KB-18-ER25
IC7480 A-2074-365-A IC W25Q128FVEIG (for SERVICE)
IC7481 6-704-099-01 IC TC7WZ08FK
IC8000 6-718-168-01 IC AK4388AET2-E2
IC8001 8-759-274-71 IC NJM4565M (TE2)
IC8002 6-707-870-01 IC TC74VHC157FT (EK)
< JACK >
J503 1-844-187-11 ETHERNET CONNECTOR ( )
J3190 1-563-330-31 JACK (IR REMOTE OUT) (DN1060)
J3191 1-563-330-31 JACK (IR REMOTE IN) (DN1060)
J6000 1-784-431-11 JACK, PIN 1P
(COAXIAL SA-CD/CD (ASSIGNABLE) IN)
< COIL >
L501 1-457-965-11 COIL,COMMON MODE CHOKE (SMD1210)
L502 1-457-965-11 COIL,COMMON MODE CHOKE (SMD1210)
L3810 1-400-791-21 INDUCTOR 10uH
< TRANSISTOR >
Q3004 6-552-936-01 TR LTC014EUBFS8TL
Q3005 6-552-936-01 TR LTC014EUBFS8TL
Q3006 6-552-936-01 TR LTC014EUBFS8TL
Q3007 6-552-936-01 TR LTC014EUBFS8TL
Q3008 6-552-936-01 TR LTC014EUBFS8TL
Q3009 6-552-936-01 TR LTC014EUBFS8TL
Q3010 6-552-892-01 TR LSCR523UBFS8TL
Q3190 6-553-268-01 TR PDTC114ET (DN1060)
Q5005 6-552-936-01 TR LTC014EUBFS8TL
Q5006 6-552-930-01 TR LTA043EUBFS8TL
Q5274 6-553-470-01 TR QM2401C1 (DN1060)
< RESISTOR >
R101 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R102 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R104 1-218-941-81 METAL CHIP 100 5% 1/16W
* R105 1-250-480-11 METAL CHIP 240 1% 1/16W
R106 1-218-941-81 METAL CHIP 100 5% 1/16W
* R107 1-250-480-11 METAL CHIP 240 1% 1/16W
R302 1-218-965-11 METAL CHIP 10K 5% 1/16W
R303 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R304 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R305 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R306 1-218-965-11 METAL CHIP 10K 5% 1/16W
R307 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R309 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R318 1-218-953-11 METAL CHIP 1K 5% 1/16W
R319 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R320 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R321 1-218-953-11 METAL CHIP 1K 5% 1/16W
R322 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R324 1-218-965-11 METAL CHIP 10K 5% 1/16W
R325 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R326 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R327 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R328 1-218-965-11 METAL CHIP 10K 5% 1/16W
R329 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R330 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R331 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R332 1-218-965-11 METAL CHIP 10K 5% 1/16W
R336 1-218-965-11 METAL CHIP 10K 5% 1/16W
R348 1-218-965-11 METAL CHIP 10K 5% 1/16W
R349 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R352 1-218-953-11 METAL CHIP 1K 5% 1/16W
R353 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R354 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R355 1-218-953-11 METAL CHIP 1K 5% 1/16W
R364 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R366 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R367 1-218-990-81 SHORT CHIP 0
R368 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R369 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R370 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R371 1-218-990-81 SHORT CHIP 0
R372 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R373 1-208-897-81 METAL CHIP 2.7K 0.5% 1/16W
R374 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R375 1-218-953-11 METAL CHIP 1K 5% 1/16W
R376 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R377 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R378 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R379 1-208-697-11 METAL CHIP 3.9K 0.5% 1/16W
R380 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R381 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R382 1-208-897-81 METAL CHIP 2.7K 0.5% 1/16W
R383 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R384 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R385 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R386 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R387 1-208-897-81 METAL CHIP 2.7K 0.5% 1/16W
R388 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R389 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R390 1-208-897-81 METAL CHIP 2.7K 0.5% 1/16W
R402 1-218-965-11 METAL CHIP 10K 5% 1/16W
R408 1-218-965-11 METAL CHIP 10K 5% 1/16W
R410 1-218-965-11 METAL CHIP 10K 5% 1/16W
R412 1-218-965-11 METAL CHIP 10K 5% 1/16W
R414 1-218-965-11 METAL CHIP 10K 5% 1/16W
R416 1-218-965-11 METAL CHIP 10K 5% 1/16W
R418 1-218-941-81 METAL CHIP 100 5% 1/16W
R419 1-218-941-81 METAL CHIP 100 5% 1/16W
R420 1-218-941-81 METAL CHIP 100 5% 1/16W
R421 1-218-941-81 METAL CHIP 100 5% 1/16W
R423 1-218-941-81 METAL CHIP 100 5% 1/16W
R427 1-218-965-11 METAL CHIP 10K 5% 1/16W
R428 1-218-965-11 METAL CHIP 10K 5% 1/16W
R429 1-218-965-11 METAL CHIP 10K 5% 1/16W
R430 1-218-941-81 METAL CHIP 100 5% 1/16W
R431 1-218-941-81 METAL CHIP 100 5% 1/16W
R432 1-218-953-11 METAL CHIP 1K 5% 1/16W
R443 1-216-864-11 SHORT CHIP 0
R449 1-216-295-91 SHORT CHIP 0
R452 1-216-864-11 SHORT CHIP 0
R462 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R463 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
Note: IC6501, IC7100, IC7400 and IC7440 on the MB-1409 board
cannot exchange with single. When these parts on the MB-
1409 board are damaged, exchange the entire mounted
board.
MB-1409
