Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN860/DN1060
155
* RB5005 1-460-727-11 COMMON MODE CHOKE COIL
RB6000 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6001 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6500 1-200-051-21 RES, NETWORK 150 (1005X4)
RB6501 1-200-051-21 RES, NETWORK 150 (1005X4)
RB6502 1-200-051-21 RES, NETWORK 150 (1005X4)
RB6503 1-200-051-21 RES, NETWORK 150 (1005X4)
< RELAY >
RY5276 1-755-695-11 RELAY (DN1060)
< TRANSFORMER >
* T501 1-697-376-11 PULSE TRANSFORMER
* T502 1-697-376-11 PULSE TRANSFORMER
< VIBRATOR >
X401 1-814-345-11 QUARTZ CRYSTAL UNITS (27MHz) (DN860)
X401 1-814-754-11 QUARTZ CRYSTAL UNIT (27MHz) (DN1060)
X3000 1-781-646-21 VIBRATOR, CERAMIC (4MHz)
X3500 1-814-607-11 QUARTZ CRYSTAL UNITS (28.224MHz) (DN860)
X3500 1-814-858-11 QUARTZ CRYSTAL UNIT (28.224MHz) (DN1060)
X6000 1-814-344-11 QUARTZ CRYSTAL UNIT (24.576MHz)
X6500 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
*************************************************************
NFC-ICON BOARD
***************
< CONNECTOR >
CN2550 1-785-466-51 CONNECTOR, FFC/FPC 7P
CN2551 1-820-821-71 CONNECTOR, FFC/FPC (LIF) 6P
*************************************************************
A-2060-600-A POWERKEY BOARD, COMPLETE (DN1060)
A-2071-924-A POWERKEY BOARD, COMPLETE (DN860)
**************************
< DIODE >
D1110 8-719-057-29 DIODE SML78423C-TP15
< TRANSISTOR >
Q1110 6-553-266-01 TR 2PD601ART
Q1111 6-553-266-01 TR 2PD601ART
< RESISTOR >
R1173 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1174 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1175 1-216-810-11 METAL CHIP 120 5% 1/10W
R1176 1-250-584-11 METAL CHIP 47 1% 1/10W
R1178 1-250-664-11 METAL CHIP 100K 1% 1/10W
R1179 1-250-664-11 METAL CHIP 100K 1% 1/10W
R1180 1-250-640-11 METAL CHIP 10K 1% 1/10W
R1181 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R1182 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R1183 1-250-648-11 METAL CHIP 22K 1% 1/10W
< SWITCH >
S1111 1-762-875-21 SWITCH, TACTILE (TUNER PRESET +)
S1112 1-762-875-21 SWITCH, TACTILE (TUNER PRESET -)
MB-1409 NFC-ICON POWERKEY STANDBY
S1113 1-762-875-21 SWITCH, TACTILE
(CONNECTION
PAIRING BLUETOOTH)
S1114 1-762-875-21 SWITCH, TACTILE (SPEAKERS)
S1115 1-762-875-21 SWITCH, TACTILE (]/1)
*************************************************************
A-2060-592-A STANDBY BOARD, COMPLETE (US, CND, TW)
A-2064-334-A STANDBY BOARD, COMPLETE (AEP, UK, AUS)
************************
< CAPACITOR >
C960 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C961 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C962 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C963 1-126-936-11 ELECT 3300uF 20% 16V
C969 1-126-960-11 ELECT 1uF 20% 50V
C970 1-126-964-11 ELECT 10uF 20% 50V
C971 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
* CNP901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D901 6-503-670-01 DI GS1G
D902 6-503-670-01 DI GS1G
D903 6-503-670-01 DI GS1G
D904 6-503-670-01 DI GS1G
D905 6-500-514-01 DIODE BAV70
D991 6-502-961-01 DI DA2J10100L
D992 6-503-579-01 DI RB521SM-30GJT2R
D994 6-503-738-01 DI CES521
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< JUMPER >
JS901 1-211-950-11 SHORT CHIP 0
< TRANSISTOR >
Q951 6-553-266-01 TR 2PD601ART
Q952 6-553-266-01 TR 2PD601ART
Q953 6-553-266-01 TR 2PD601ART
< RESISTOR >
R960 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R961 1-216-833-11 METAL CHIP 10K 5% 1/10W
R963 1-216-833-11 METAL CHIP 10K 5% 1/10W
R971 1-249-401-11 CARBON 47 5% 1/4W
R972 1-249-399-11 CARBON 33 5% 1/4W
R973 1-216-841-11 METAL CHIP 47K 5% 1/10W
R974 1-216-809-11 METAL CHIP 100 5% 1/10W
R981 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R982 1-216-813-11 METAL CHIP 220 5% 1/10W
R984 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
0 RY951 1-755-541-11 RELAY
