Ref. No. Part No. Description Remark
STR-DN860/DN1060
156
< TRANSFORMER >
0 T902 1-697-422-11 POWER TRANSFORMER (SUB) (AEP, UK, AUS)
0 T902 1-697-423-11 POWER TRANSFORMER (SUB) (US, CND, TW)
*************************************************************
MISCELLANEOUS
**************
3 1-458-765-31 CARD WLAN/BT COMBO
51 1-828-240-61 WIRE (FLAT TYPE) (22 CORE) (DN860)
52 1-828-360-61 WIRE (FLAT TYPE) (19 CORE) (DN860)
* 53 3-703-150-11 CLAMP (DN860)
101 1-828-240-61 WIRE (FLAT TYPE) (22 CORE) (DN1060)
102 1-828-360-61 WIRE (FLAT TYPE) (19 CORE) (DN1060)
103 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (DN1060)
* 105 3-703-150-11 CLAMP (DN1060)
156 1-828-412-61 WIRE (FLAT TYPE) (27 CORE)
159 1-848-827-11 HDMI CABLE (DN1060)
160 1-828-308-61 WIRE (FLAT TYPE) (7 CORE)
161 1-828-677-61 WIRE (FLAT TYPE) (6 CORE)
*
201 1-500-082-11 CLAMP, SLEEVE FERRITE
0 206 1-834-966-41 POWER-SUPPLY CORD (AEP)
0 206 1-833-566-21 POWER-SUPPLY CORD (AUS)
0 206 1-837-308-12 CORD, POWER-SUPPLY (US, CND)
0 206 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 206 1-839-999-21 POWER-SUPPLY CORD (UK)
Q1550 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1551 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1600 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1601 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1650 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1651 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1700 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1701 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1750 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1751 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1800 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1801 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q1850 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q1851 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0 F901 1-532-465-33 FUSE (T3.15AL/250V) (AEP, UK, AUS)
0 F901 1-532-506-33 FUSE (T6.3AL/250V) (TW)
0 F901 1-533-311-12 FUSE, GLASS (DIA.5) (8A/125V) (US, CND)
0 T901 1-697-442-11 POWER TRANSFORMER (MAIN)
(DN860: US, CND, TW)
0 T901 1-697-443-11 POWER TRANSFORMER (MAIN)
(DN860: AEP, UK, AUS)
0 T901 1-697-439-11 POWER TRANSFORMER (MAIN)
(DN1060: US, CND)
0 T901 1-697-440-11 POWER TRANSFORMER (MAIN)
(DN1060: AEP, UK, AUS)
*************************************************************
ACCESSORIES
************
1-493-014-11 REMOTE COMMANDER (RMT-AA130U)
(including BATTERY LID)
1-542-830-11 MEASUREMENT MIC (MONO)
(Optimizer microphone (ECM-AC2))
1-754-852-11 ANTENNA (FM)
4-477-465-31 HI-RES LABEL
STANDBY
Note: If wire (fl at type) is replaced, install it after bending it in the
same form as that before replacement.
* Replacement of Q1550, Q1551, Q1600, Q1601, Q1650,
Q1651, Q1700, Q1701, Q1750, Q1751, Q1800, Q1801, Q1850
and Q1851 on the MAIN board used in this unit requires L type
screw driver.
