STR-DN860/DN1060
93
Pin No. Pin Name I/O Description
F12 AVSS33_USB_POP1 - Ground terminal
F13 NC - Not used
F14 NC - Not used
F15, F16 DGND12_K - Ground terminal
F17 AGND33_3 - Ground terminal
F18 AVDD33_1 - Power supply terminal (+3.3V)
F19 AGND12_ 2 - Ground terminal
F20 AGND33_1 - Ground terminal
F23 DVCC33_IO_5 - Power supply terminal (+3.3V)
F26 AVDD33_PLLGP - Power supply terminal (+3.3V)
F27 CH0_P O TMDS data (positive) output to the HDMI ARC OUT connector
F28 CH0_M O TMDS data (negative) output to the HDMI ARC OUT connector
G1 to G3
GPIO4, GPIO23,
GPIO22
-Not used
G4 AMUTE - Not used
G5 GPIO20 - Not used
G8 DVCC33_IO_2 - Power supply terminal (+3.3V)
G11 AVDD12_S - Power supply terminal (+1.2V)
G12 AVDD33_S - Power supply terminal (+3.3V)
G14 DVCC33_IO_1 - Power supply terminal (+3.3V)
G18 AGND33_2 - Ground terminal
G21 AGND12_1 - Ground terminal
G22 DVCC33_IO_5 - Power supply terminal (+3.3V)
G26 AVDD12_HDMI_D - Power supply terminal (+1.2V)
G27 CLK_P O TMDS clock (positive) signal output to the HDMI ARC OUT connector
G28 CLK_M O TMDS clock (negative) signal output to the HDMI ARC OUT connector
H1 EFPWRQ - Not used
H2 GPIO5 O Jig mode selection signal output to the system controller
H3 GPIO9 - Not used
H4 DGND12_K - Ground terminal
H5, H6 DDRVCCIO1 - Power supply terminal (+1.5V)
H7 DGND12_K - Ground terminal
H8, H14
DVCC33_IO_2,
DVCC33_IO_1
- Power supply terminal (+3.3V)
H25 AVDD12_HDMI_C - Power supply terminal (+1.2V)
H26
AVDD12_HDMI_
D_SUB
- Power supply terminal (+1.2V)
H27 CH2_P_SUB I TMDS data (positive) input from the HDMI IN 2 connector
H28 CH2_M_SUB I TMDS data (negative) input from the HDMI IN 2 connector
J1 to J6 NC - Not used
J11, J12 DVCC12_K - Power supply terminal (+1.2V)
J13 DGND12_K - Ground terminal
J14, J15 DVCC12_K - Power supply terminal (+1.2V)
J16 DGND12_K - Ground terminal
J17 to J19 DVCC12_K - Power supply terminal (+1.2V)
J25
AVDD12_HDMI_
C_SUB
- Power supply terminal (+1.2V)
J27 CH1_P_SUB I TMDS data (positive) input from the HDMI IN 2 connector
J28 CH1_M_SUB I TMDS data (negative) input from the HDMI IN 2 connector
K1, K2 NC - Not used
K3, K4 NC - Not used
K5 DDRVCCIO1 - Power supply terminal (+1.5V)
K6, K7, K9 DGND12_K - Ground terminal
K11, K12 DVCC12_K - Power supply terminal (+1.2V)
K13 DGND12_K - Ground terminal
K14, K15 DVCC12_K - Power supply terminal (+1.2V)
K16 DGND12 _K - Ground terminal
