Sony STR-DN1060 - Page 94

STR-DN860/DN1060
94
Pin No. Pin Name I/O Description
K17 to K19 DVCC12_K - Power supply terminal (+1.2V)
K23 AVSS33_DAC - Ground terminal
K27 CH0_P_SUB I TMDS data (positive) input from the HDMI IN 2 connector
K28 CH0_M_SUB I TMDS data (negative) input from the HDMI IN 2 connector
L1 NC - Not used
L2 NC - Not used
L3, L4 NC - Not used
L5 DDRVCCIO1 - Power supply terminal (+1.5V)
L10 DVCC12_K - Power supply terminal (+1.2V)
L11 t o L18 D GND12 _ K - G ro und te rm inal
L19 DVCC12_K - Power supply terminal (+1.2V)
L22 AVSS33_PLLGP - Ground terminal
L24 VOUTHSYNC - Not used
L25 VOUTVSYNC - Not used
L27 CLK_P_SUB I TMDS clock (positive) signal input from the HDMI IN 2 connector
L28 CLK_M_SUB I TMDS clock (negative) signal input from the HDMI IN 2 connector
M1 NC - Not used
M2 NC - Not used
M3 DDRVCCIO1 - Power supply terminal (+1.5V)
M4 DGND12_K - Ground terminal
M5, M6 NC - Not used
M8 DDRVCCIO1 - Power supply terminal (+1.5V)
M10 DVCC12_K - Power supply terminal (+1.2V)
M11 to M18 DGND12_K - Ground terminal
M19 DVCC12_K - Power supply terminal (+1.2V)
M22 AVSS33_HDMI - Ground terminal
M27 HDMI_RX_2 I TMDS data (positive) input from the HDMI IN 1 connector
M28 HDMI_RX_2B I TMDS data (negative) input from the HDMI IN 1 connector
N1 NC - Not used
N2 NC - Not used
N3 NC - Not used
N4 NC - Not used
N5 NC - Not used
N6 NC - Not used
N7 DDRVCCIO1 - Power supply terminal (+1.5V)
N8 DDRVREF_A I Reference voltage (+0.75V) input terminal for SD-RAM
N10 DVCC12_K - Power supply terminal (+1.2V)
N11 to N18 DGND12_K - Ground terminal
N19 DVCC12_K - Power supply terminal (+1.2V)
N20 AVSS33_HDMI_SUB - Ground terminal
N23 AVDD12_HDMI_RX - Power supply terminal (+1.2V)
N27 HDMI_RX_1 I TMDS data (positive) input from the HDMI IN 1 connector
N28 HDMI_RX_1B I TMDS data (negative) input from the HDMI IN 1 connector
P3, P4 NC - Not used
P5 NC - Not used
P6 NC - Not used
P8 DDRVCCIO1 - Power supply terminal (+1.5V)
P10 DVCC12_K - Power supply terminal (+1.2V)
P11 to P18 DGND12_K - Ground terminal
P19, P20 DVCC12_K - Power supply terminal (+1.2V)
P22 VOUTCLK - Not used
P23 to P26
VOUTD14, VOUTD12,
VOUTD13, VOUTD15
-Not used
P27 HDMI_RX_0 I TMDS data (positive) input from the HDMI IN 1 connector
P28 HDMI_RX_0B I TMDS data (negative) input from the HDMI IN 1 connector
R1 NC - Not used
