STR-DN860/DN1060
95
Pin No. Pin Name I/O Description
R2 NC - Not used
R3, R4 NC - Not used
R5 NC - Not used
R7 DDRVCCIO1 - Power supply terminal (+1.5V)
R8 DGND12_K - Ground terminal
R10 DVCC12_K - Power supply terminal (+1.2V)
R11 to R19 DGND12_K - Ground terminal
R20 DVCC12_K - Power supply terminal (+1.2V)
R22 AVSS33_HDMI_RX - Ground terminal
R23, R24 VOUTD8, VOUTD3 - Not used
R25 AVDD33_HDMI_SUB - Power supply terminal (+3.3V)
R26 AVDD33_HDMI_RX - Power supply terminal (+3.3V)
R27 HDMI_RX_C I TMDS clock (positive) signal input from the HDMI IN 1 connector
R28 HDMI_RX_CB I TMDS clock (negative) signal input from the HDMI IN 1 connector
T1 to T3 NC - Not used
T4 NC - Not used
T5, T6 NC - Not used
T7 DGND12_K - Ground terminal
T8 DDRVCCIO1 - Power supply terminal (+1.5V)
T10 DVCC12_K - Power supply terminal (+1.2V)
T11 to T18 DGND12_K - Ground terminal
T19, T20 DVCC12_K - Power supply terminal (+1.2V)
T22 AVSS33_BG - Ground terminal
T26 VOUTD10 - Not used
T27 AVDD33_BG - Power supply terminal (+3.3V)
U3 to U5 NC - Not used
U6 NC - Not used
U7 DDRVCCIO1 - Power supply terminal (+1.5V)
U8 DGND12_K - Ground terminal
U10 DVCC12_K - Power supply terminal (+1.2V)
U12 to U19 DGND12_K - Ground terminal
U20 DVCC12_K - Power supply terminal (+1.2V)
U21 DVCC33_IO_4 - Power supply terminal (+3.3V)
U22 AVSS33_X - Ground terminal
U23 to U26
VOUTD9, VOUTD7,
VOUTD6, VOUTD11
-Not used
U27 NC - Not used
U28 NC - Not used
V1 NC - Not used
V2 NC - Not used
V3 NC - Not used
V4 NC - Not used
V5, V6 NC - Not used
V7 DGND12_K - Ground terminal
V8 DDRVREF_B I Reference voltage (+0.75V) input terminal for SD-RAM
V10 DGND12_K - Ground terminal
V11 DVCC12_K - Power supply terminal (+1.2V)
V12 to V17 DGND12_K - Ground terminal
V18 DVCC12_K - Power supply terminal (+1.2V)
V19 DGND12_K - Ground terminal
V20 DVCC12_K - Power supply terminal (+1.2V)
V21 DVCC33_IO_4 - Power supply terminal (+3.3V)
V22 AVDD33_X - Power supply terminal (+3.3V)
V23 to V25
VOUTD2, VOUTD4,
VOUTD5
-Not used
V28 NC - Not used
