10. VIDEO IN/OUT (*) jacks
11. COMPONENT VIDEO IN/OUT (*) jacks
12. FM ANTENNA terminal
13. OPTICAL IN jacks
*
You must connect your TV to HDMI OUT or MONITOR OUT to watch images from the selected
input.
**
You can also use this port for maintenance and service.
[6] Parts and Controls Receiver (STR-DN860)
Front panel (STR-DN860) (upper section)
1. (on/standby)
2. On/standby indicator
3. SPEAKERS
4. CONNECTION PAIRING BLUETOOTH
Operates the BLUETOOTH function.
5. TUNER PRESET +/–
6. NFC sensor
7. A.F.D./2CH, MOVIE, MUSIC
8. Display panel
9. SOUND OPTIMIZER
10. SLEEP
11. DISPLAY MODE
Switches information on the display panel.
12. DIMMER
Adjusts the brightness of the display panel in 3 levels.
13. Remote control sensor
Receives signals from remote control.
