BVM-A14
2-9
. 575/50i (15kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
2. H CENTER
H PHASE
H BLK LEFT
H BLK RIGHT
Copy the above-described data to the following modes.
. 720/60p (45 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
. 720/50p (37 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
. 1080/48i (27 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
. 1080/50i (28 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
. 480/60p (31 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
2. H CENTER
H PHASE
H BLK LEFT
H BLK RIGHT
Copy the above-described data to the following modes.
. 480/60i (15 kHz) 16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
2. H CENTER
H PHASE
H BLK LEFT
H BLK RIGHT
Copy the above-described data to the following modes.
. 576/50p (31 kHz)16:9 NORMAL mode H blanking
adjustment
1. Adjust the H. CENTER, H. PHASE, H. BLK. LEFT
and H. BLK. RIGHT data in the same manner as steps
3 to 11 of the 1080/60i (33 kHz) 16:9 NORMAL
mode.
2. H CENTER
H PHASE
H BLK LEFT
H BLK RIGHT
Copy the above-described data to the following modes.
MODE10 480/60p (31kHz) 4:3 NORMAL
MODE13 480/60i (15kHz) 16:9 NORMAL
MODE23 576/50p (31kHz) 16:9 NORMAL
MODE27 575/50i (15kHz) 16:9 NORMAL
To Next Page
