13. Change the SCREEN MODE for the following modes
as well, and perform adjustments in the same way.
. Common items for modes
DY inclination
Up/down V PIN distortion
Horizontal trapezoidal distortion
MODE 2
MODE 3
MODE 4
MODE 5
MODE 6
MODE 7
MODE 8
MODE 9
MODE 10
MODE 11
MODE 12
MODE 13
MODE 14
MODE 15
MODE 16
MODE 17
MODE 18
MODE 19
MODE 20
MODE 21
MODE 22
MODE 23
MODE 24
MODE 25
MODE 26
MODE 27
MODE 28
1080/60i(33kHz)
1035/60i(33kHz)
720/60P(45kHz)
480/60P(31kHz)
480/60i(15kHz)
1080/48i(27kHz)
1080/50i(28kHz)
720/50P(37kHz)
575/50P(31kHz)
575/50i(15kHz)
16:9
16:9
16:9
16:9
16:9
16:9
16:9
4:3
4:3
16:9
16:9
4:3
4:3
16:9
16:9
16:9
16:9
16:9
16:9
16:9
16:9
4:3
4:3
16:9
16:9
4:3
4:3
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
NORMAL SCAN
UNDER SCAN
. Items differing between modes
TLV
H SIZE
H CENTER
H PHASE
V SIZE
V CENTER
H LIN BAL
H LIN TOP
H LIN BOTTOM
V LIN AMP
V LIN BAL
H PIN
H PIN BAL
H KEY
H KEY BAL
H CORNER S
Fig. 1-10
Fig. 1-11
H CORNER
PIN
H CORNER
S
