Menu Structure
Chapter 2 Menu
SYSTEM CONFIGURATION [D] Sets the system of the remote control function, LAN, etc. (page
42)
NETWORK [D1] Sets the IP address, subnet mask and default gateway. (page 43)
PARALLEL REMOTE [D2] Sets the remote control function. (page 44)
POWER [D3] Sets the condition of the monitor when the main power or
MONITOR I/1 switch is turned on. (page 44)
BLANKING SETTINGS [D4] Adjusts the data for the picture. (page 45)
ON SCREEN SET [D5] Sets the data for the screen display. (page 45)
PASSWORD [D6] Sets the passwords for the menu. (page 45)
MAINTENANCE [D7] Displays the menu for maintenance. (page 45)
INSTALLATION SETTINGS [E] Sets the initial value of landing, alignment, etc. (page 46)
LANDING ADJUST [E1] Corrects the shift of beam landing caused by the earth’s
magnetism. (page 47)
ALIGNMENT [E2] Adjusts the position and size of the picture. (page 47)
DIGITAL UNIFORMITY ADJ [E3] Adjusts the color unevenness of the CRT. (page 48)
FILE MANAGEMENT [F] Saves, copies and deletes the system data. (page 50)
SAVE TO [F1] Writes the data. (page 51)
COPY FROM [F2] Reads or copies the data. (page 51)
DELETE [F3] Deletes the file. (page 51)
DATA MAINTENANCE [F4] Services the system data. (page 51)
STATUS [G] Displays the information about the monitor or options installed in
the monitor. (page 52)
CH STATUS [G1] Displays the information of the used channel. (page 53)
SLOT STATUS [G2] Displays the data about the optional board installed in the option
slot 1 to 3. (page 53)
MODEL NAME Displays the model name. (page 53)
SERIAL NO Displays the serial number. (page 53)
SOFTWARE VERSION Displays the software version. (page 53)
OPERATION TIME Displays the operation time. (page 53)
CRT TURN ON TIME Displays how long the CRT is used. (page 53)
IP ADDR Displays the IP address of the monitor. (page 53)
CONTROLLER STATUS [G3] Displays the information on the controller. (page 53)
CONTROLLER [H] Sets the network of the controller. (page 54)
MONITOR ID DISPLAY [H1] Sets the display method of the monitor select display window.
(page 54)
NETWORK SETTING [H2] Displays the NETWORK SETTING menu. (page 54)
NETWORK SW Sets the Ethernet connections. (page 54)
SNMP SETTINGS [H3] Sets CONTACT, NAME, LOCATION and TRAP. (page 54)
KEY PROTECT [I] Sets whether or not to lock the buttons on the control unit. (page
55)
Main menu Level 1 Functions
