Sony TRINITRON KV-21FA310 - Page 28

KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
28
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
NTSC
Init Video YUV 16:09
Data
FIX
1 HFFR
AFC FREE RUN ( AFC1 FORCE FREE RUN )
0
FIX
2HFUP
HFREE UP ( H FREE RUN FREQUENCY UP [ 700 Hz ]
0
FIX
3JSWW
VJP WIDTH ( JUMP PULSE WIDTH )
0
FIX 4 EWCL V/EW DAC CLK CONTROL ( EW/VRAMP DA CLOCK SELECT ) 0 0 0 N/A
FIX
5XF0A
FREE RUN OFFSET ( VCXO FREE RUN ADJUST)
0
FIX
6BGST
BG START ( BGP [ FOR PLL ] TIMING )
16
16 1 N/A
FIX
7 XPHA
VCXO CTL ( VXCO PHASE ADJUST )
10
FIX
8 HRMP
Ramp Slew Rate ( AFC2 TIME CONSTANT )
3
FIX
9RPLU
Ref Charge pump ( REF PLL TIME CONSTANT )
3
FIX
10 RPLB
Ref VCO ( REF PLL TIME CONSTANT )
1
FIX
11 XF0B
VCXO FREE RUN ( VXCO Fo ADJUST )
0
FIX
12 RPLS
REF FB SW ( REF VCO FB LOOP SELECT )
0
FIX
13 SSM
Sync Sepa Mask ( SyncSepaMasking CONTROL )
0
FIX
14 VSAG
V-sag ( V-SAG prevent ON )
0
FIX
15 AFC2
AFC2 Gain ( AFC2 GAIN CONTROL )
3
FIX
16 VRFL
V RAMP FIL OFF ( V RAMP FILTER SWITCHING OFF )
1
FIX
17 SSLP
LPY SYNC ( LFP pre SYNC SEPA ON/OFF
1
FIX
18 XPLU
B PLL Change pump ( ACP TIME CONSTANT )
1
FIX
19 8FSC
8FSC SEL ( 8fsCLK Skew OFF )
1
10N/A
FIX
20 4FS2
4FSC SEL2 ( 4fsCLK Skew OFF )
1
10N/A
FIX
21 CDM2
V_CD_MODE2 ( V_LOGIC SW )
1
FIX
22 BGPC
Add. FTN BGP C ( BGP C )
0
FIX
23 MHDL
Add. FTN BGP SEL ( BBP SEL )
1
FIX
24 BFRE
V FREE ( FORCE V FREE RUN )
0
No.
Service
Group
DEFD
Name Item name & ( Description )Fix/ Var
