KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
29
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
NTSC
Init Video YUV 16:09
Data
FIX 25 HRPP AFC2 RAMP POS ( FRAMP RRAMP H OUT CONTROL RANGE 8
FIX
26 DSC
K
CLOCK SEL ( DS DAC CLK SW 2 )
1
110
FIX
27 VBH
K
VBLK HALFKIL ( V BLK HALF KILL )
0
FIX
28 VPW
V PLS WIDTH ( V Pulse Wide )
1
FIX 29 DTH
D THRESHOLD LEVEL ( DITHER THRESHOLD LEVEL
CONTROL AT IIC AUTOD= ON
0
FIX
30 SLON
LPF SYNC ON ( LPF SYNC ON )
1
FIX 31 VSSW
SYNC SLICE LVL(V)_W ( SYNC SLICE LEVEL [ V ] Wide Window
0
FIX
32 AF2S
AFC2_SEL ( ADC2 TIMING SW )
0
FIX
33 VSL2
V_SYNC_LPF_2 ( DIGITAL V_SINC_LPF [ Fall ] )
0
FIX
34 VSL1
V_SYNC_LPF_1 ( DIGITAL V_SINC_LPF [ Rise ] )
1
FIX
35 VYUV
YUV VSIZE OFFSET ( YUV V-SIZE OFFSET )
8
FIX
36 VYVP
YUV VPOS OFFSET ( YUV V-POSITION OFFSET )
8
FIX
37 VYHS
YUV HSIZE OFFSET ( YUV H-SIZE OFFSET )
8
FIX
38 VYHP
YUV HPOS OFFSET ( YUV H-POSITION OFFSET)
7
FIX
39 VSHE
V-SHRINK MODE ( V-SHRINK MODE for AV )
0
FIX
40 VYRB
YUV RBLK ( YUV RBLK OFFSET )
7
FIX
41 VYLB
YUV LBLK ( YUV LBLK OFFSET )
7
DEFD
Fix/ Var No. Name Item name & ( Description )
Service
Group
