KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
30
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
NTSC
Init Video YUV 16:09
Data
FIX 1 PCLP
pedestal CLAMP ON/OFF ( SYNC TIP/PEDESTAL CLAMP
SELECT )
0
FIX 2 VRT
VRT Voltage ( ADC REFERENCE [ 00:1.15Vpp 01:1.25 Vpp
10:1.35 Vpp 11:1.45 Vpp ] )
1
FIX
3 14HI
INV 14H CLK ( 4fsc [ Skew ] CLK POLARITY )
0
00N/A
FIX
4 14HD
14H CLK DLY ( 4fscCLK [ Skew ] CLK DELAY ADJUST )
0
00N/A
FIX
5DSI
INV DS CLK ( 8fscCLK POLARITY )
0
00N/A
FIX
6DSD
DS CLK DLY ( 8fscCLK DELAY ADJUST )
0
00N/A
FIX
7 ADCD
AD CLK DLY ( ADC CLK DELAY ADJUSTO )
0
01N/A
FIX
84FSC
4FSC SW ( AD/LOGIC CLK SWAP )
0
FIX
9WSTH
WEAK_SIG_VTH ( WEAK_SIGNAL VTH )
0
FIX
10 WSVA
WEAK SIG VIDEO ATT ( WEAK SIGNAL VIDEO ATT )
0
00N/A
FIX
11 WSCA
WEAK SIG CHROMA ATT (WEAK SIGNAL CHROMA ATT)
0
00N/A
FIX
12 VREF
VREF_SEL ( AD REFERENCE SELECT [ VZ ] )
0
NTSC
Init
Data
FIX 1
HT
HT ( HALF TONE LEVEL )
0
FIX 2
OSLR
OSD LVL R ( R OSD LEVEL )
25
FIX
3OSLG
OSD LVL G ( G OSD LEVEL )
25
FIX
4OSDC
OSD COMP ( OSD COMP )
0
FIX
5OSLB
OSD LVL B ( B OSD LEVEL )
25
Name
Service
Group
Fix/ Var No.
Name
Item name & ( Description )
No. Item name & ( Description )Fix/ Var
OTHEROSD
