Sony TRINITRON KV-21FA310 - Page 61

61
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C115 1-164-739-11 CERAMIC CHIP 560pF 5% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C200 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C202 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C203 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C204 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
(KV-21FA310LN/21FA310LS ONLY)
C204 1-216-864-11 CHIP, CONDUCTOR 0
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C205 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
(KV-21FA310LN/21FA310LS ONLY)
C205 1-216-864-11 CHIP, CONDUCTOR 0
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C212 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C213 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C220 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C301 1-126-956-91 ELECT 0.1µF 20% 50V
C302 1-126-956-91 ELECT 0.1µF 20% 50V
C303 1-126-956-91 ELECT 0.1µF 20% 50V
C304 1-126-956-91 ELECT 0.1µF 20% 50V
C305 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C306 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C307 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C309 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C313 1-126-956-91 ELECT 0.1µF 20% 50V
C318 1-126-964-11 ELECT 10µF 20% 50V
C319 1-126-964-11 ELECT 10µF 20% 50V
C325 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C326 1-164-505-11 CERAMIC CHIP 2.2µF 16V
C328 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C330 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C337 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C351 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C370 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C390 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C400 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
(KV-21FA310LN/21FA310LS ONLY)
C401 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C402 1-164-174-11 CERAMIC CHIP 0.0082µF 10% 25V
(KV-21FA310LN/21FA310LS ONLY)
C403 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
(KV-21FA310LN/21FA310LS ONLY)
C404 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
(KV-21FA310LN/21FA310LS ONLY)
C405 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C406 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C407 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
(KV-21FA310LN/21FA310LS ONLY)
C407 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C408 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
(KV-21FA310LN/21FA310LS ONLY)
C408 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C409 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C409 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C410 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C410 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C411 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
(KV-21FA310LN/21FA310LS ONLY)
C412 1-126-960-11 ELECT 1µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C412 1-124-252-00 ELECT 0.33µF 20% 50V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C413 1-126-963-11 ELECT 4.7µF 20% 50V
C414 1-126-961-11 ELECT 2.2µF 20% 50V
C415 1-126-963-11 ELECT 4.7µF 20% 50V
C416 1-126-960-11 ELECT 1µF 20% 50V
C417 1-126-960-11 ELECT 1µF 20% 50V
(ALL EXCEPT KV-21FA310LN/21FA310LS)
C418 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C419 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C420 1-126-960-11 ELECT 1µF 20% 50V
C421 1-126-965-91 ELECT 22µF 20% 50V
C422 1-126-960-11 ELECT 1µF 20% 50V
C423 1-126-963-11 ELECT 4.7µF 20% 50V
C424 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C430 1-126-963-11 ELECT 4.7µF 20% 50V
(ALL EXCEPT KV-21FM120)
A
