62
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C431 1-126-963-11 ELECT 4.7µF 20% 50V
(ALL EXCEPT KV-21FM120)
C436 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C440 1-126-965-91 ELECT 22µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C441 1-126-965-91 ELECT 22µF 20% 50V
(KV-21FA310LN/21FA310LS ONLY)
C450 1-126-943-11 ELECT 2200µF 20% 25V
C451 1-126-959-11 ELECT 0.47µF 20% 50V
C452 1-126-960-11 ELECT 1µF 20% 50V
C457 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C457 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
(ALL EXCEPT 21FA310LN/21FA310LS)
C458 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
(KV-21FA310LN/21FA310LS ONLY)
C458 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
(ALL EXCEPT 21FA310LN/21FA310LS)
C460 1-126-943-11 ELECT 2200µF 20% 25V
C461 1-126-943-11 ELECT 2200µF 20% 25V
C462 1-126-943-11 ELECT 2200µF 20% 25V
C463 1-126-943-11 ELECT 2200µF 20% 25V
C470 1-126-935-11 ELECT 470µF 20% 16V
(KV-21FA310LN/21FA310LS ONLY)
C501 1-126-959-11 ELECT 0.47µF 20% 50V
C502 1-102-112-00 CERAMIC 330pF 10% 50V
C503 1-106-383-00 MYLAR 0.047µF 10% 200V
C504 1-102-228-00 CERAMIC 470pF 10% 500V
C505 1-102-228-00 CERAMIC 470pF 10% 500V
!
C506 1-117-214-11 CERAMIC 0.001µF 10% 2KV
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
!
C506 1-162-116-00 CERAMIC 680pF 10% 2KV
(KV-24FS120/25FS120LN/25FS120LS ONLY)
!
C507 1-117-642-11 FILM 8200pF 3% 1.2KV
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
!
C507 1-127-717-21 FILM 19000pF 3% 1.2KV
(KV-24FS120/25FS120LN/25FS120LS ONLY)
!
C508 1-129-722-00 FILM 0.047µF 5% 630V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
!
C508 1-130-895-00 FILM 0.056µF 5% 400V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C509 1-126-964-11 ELECT 10µF 20% 50V
C510 1-117-214-11 CERAMIC 0.001µF 10% 2KV
C511 1-115-521-11 FILM 0.82µF 5% 250V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C511 1-117-813-11 FILM 0.75µF 5% 250V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C512 1-104-987-11 MYLAR 0.001µF 5% 200V
C513 1-106-383-00 MYLAR 0.047µF 10% 200V
C514 1-115-519-11 FILM 0.82µF 5% 250V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C514 1-115-521-11 FILM 0.56µF 5% 250V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C515 1-107-651-11 ELECT 4.7µF 20% 250V
C516 1-117-661-11 ELECT 0.15µF 5% 250V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C519 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C519 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C520 1-126-965-91 ELECT 22µF 20% 50V
C521 1-126-960-11 ELECT 1µF 20% 50V
C522 1-102-244-00 CERAMIC 220pF 10% 500V
C523 1-165-529-11 MYLAR 0.22µF 10 275V
C525 1-164-646-11 CERAMIC 2200pF 10% 500V
C526 1-102-244-00 CERAMIC 220pF 10% 500V
C527 1-107-645-11 ELECT 22µF 20% 200V
C529 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C534 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C534 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C535 1-137-372-11 MYLAR 0.022µF 5% 50V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C536 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
C536 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
(KV-24FS120/25FS120LN/25FS120LS ONLY)
C537 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C539 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C542 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C544 1-126-967-11 ELECT 47µF 20% 50V
C545 1-126-969-11 ELECT 220µF 20% 50V
C546 1-137-194-81 FILM 0.47µF 5% 50V
A
