63
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
C549 1-101-821-00 CERAMIC 0.0022µF 500V
C550 1-104-666-11 ELECT 220µF 20% 25V
C551 1-126-960-11 ELECT 1µF 20% 50V
C552 1-126-964-11 ELECT 10µF 20% 50V
C553 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C554 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C555 1-101-821-00 CERAMIC 0.0022µF 500V
C558 1-162-318-11 CERAMIC 0.001µF 10% 500V
C559 1-216-864-11 SHORT CHIP
C560 1-216-833-11 METAL CHIP 10K 5% 1/10W
C561 1-126-963-11 ELECT 4.7µF 20% 50V
C562 1-104-666-11 ELECT 220µF 20% 25V
C563 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C566 1-107-635-11 ELECT 4.7µF 20% 160V
C570 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C571 1-104-665-11 ELECT 100µF 20% 25V
C581 1-136-161-00 FILM 0.047µF 5% 50V
C582 1-106-387-00 MYLAR 0.068µF 10% 200V
C585 1-104-666-11 ELECT 220µF 20% 25V
!
C588 1-137-417-11 MYLAR 0.015µF 10% 100V
C589 1-128-560-11 ELECT 22µF 20% 100V
C590 1-126-964-11 ELECT 10µF 20% 50V
C594 1-123-024-21 ELECT 33µF 160V
C595 1-104-666-11 ELECT 220µF 20% 25V
C597 1-104-666-11 ELECT 220µF 20% 25V
C600 1-126-964-11 ELECT 10µF 20% 50V
C601 1-117-703-11 CERAMIC 0.0047µF 250V
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
!
C602 1-165-529-11 MYLAR 0.22µF 10 275V
!
C603 1-165-529-11 MYLAR 0.22µF 10 275V
!
C605 1-117-699-11 CERAMIC 0.001µF 99% 250V
C609 1-126-942-61 ELECT 1000µF 20% 25V
C610 1-164-645-11 CERAMIC 1000pF 10% 500V
C611 1-126-971-11 ELECT 470µF 20% 50V
C612 1-126-961-11 ELECT 2.2µF 20% 50V
C613 1-161-964-91 CERAMIC 0.0047µF 250V
C615 1-161-964-91 CERAMIC 0.0047µF 250V
C616 1-126-943-11 ELECT 2200µF 20% 25V
C617 1-107-935-11 ELECT 330µF 20% 100V
C618 1-107-935-11 ELECT 330µF 20% 100V
C620 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C621 1-117-893-11 ELECT 470µF 20% 250V
(ALL EXCEPT KV-21FM120)
C621 1-165-921-11 ELECT 390µF 20% 250V
(KV-21FM120 ONLY)
C624 1-107-636-11 ELECT 10µF 20% 160V
C625 1-126-964-11 ELECT 10µF 20% 50V
C629 1-117-893-11 ELECT 470µF 20% 250V
(ALL EXCEPT KV-21FM120)
C629 1-165-921-11 ELECT 390µF 20% 250V
(KV-21FM120 ONLY)
!
C631 1-113-896-11 CERAMIC 220pF 10% 250V
C632 1-126-967-11 ELECT 47µF 20% 50V
C633 1-136-479-11 FILM 0.001µF 5% 100V
C634 1-126-947-11 ELECT 47µF 20% 35V
C635 1-126-963-11 ELECT 4.7µF 20% 50V
C636 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C637 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C638 1-104-665-11 ELECT 100µF 20% 25V
C640 1-164-645-11 CERAMIC 1000pF 10% 500V
C642 1-126-969-11 ELECT 220µF 20% 50V
C643 1-130-777-00 MYLAR 0.1µF 5% 100V
C645 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C647 1-126-947-11 ELECT 47µF 20% 35V
C648 1-104-330-91 CERAMIC 470pF 10% 1KV
(ALL EXCEPT KV-21FM120)
C648 1-125-969-91 CERAMIC 680pF 10% 1KV
(KV-21FM120 ONLY)
C650 1-126-942-61 ELECT 1000µF 20% 25V
C651 1-126-942-61 ELECT 1000µF 20% 25V
C652 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C655 1-104-330-91 CERAMIC 470pF 10% 1KV
(ALL EXCEPT KV-21FM120)
C655 1-125-969-91 CERAMIC 680pF 10% 1KV
(KV-21FM120 ONLY)
C660 1-126-947-11 ELECT 47µF 20% 35V
C661 1-104-665-11 ELECT 100µF 20% 25V
C665 1-104-665-11 ELECT 100µF 20% 25V
C672 1-137-756-22 FILM 22000pF 3% 800V
(ALL EXCEPT KV-21FM120)
C672 1-165-608-11 FILM 15000pF 3% 800V
(KV-21FM120 ONLY)
C673 1-126-963-11 ELECT 4.7µF 20% 50V
!
C680 1-117-699-11 CERAMIC 0.001µF 99% 250V
C690 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
A
