Sony TRINITRON KV-21FA310 - Page 64

64
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
CONNECTOR
* CN002 1-564-509-11 PLUG, CONNECTOR 6P
(KV-21FA310LN/21FS310LS ONLY)
* CN002 1-564-510-11 PLUG, CONNECTOR 7P
(ALL EXCEPT KV-21FA310LN/21FS310LS)
* CN003 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P
* CN005 1-564-515-11 PLUG, CONNECTOR 12P
(ALL EXCEPT KV-21FA310LN/21FS310LS)
* CN401 1-564-507-11 PLUG, CONNECTOR 4P
(KV-21FA310LN/21FS310LS ONLY)
* CN501 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
* CN515 1-580-798-11 CONNECTOR PIN (DY) 6P
(ALL EXCEPT KV-21FA310LN/21FS310LS)
* CN586 1-564-509-11 PLUG, CONNECTOR 6P
! * CN600 1-580-843-11 PIN, CONNECTOR (POWER)
DIODE
D002 8-719-109-89 DIODE RD5.6ESB2
D003 8-719-110-17 DIODE RD10ESB2
D004 8-719-110-17 DIODE RD10ESB2
D005 8-719-110-17 DIODE RD10ESB2
D006 8-719-921-44 DIODE MTZJ-5.1C
D007 8-719-982-22 DIODE MTZJ-30D
D046 8-719-109-89 DIODE RD5.6ESB2
D047 8-719-109-89 DIODE RD5.6ESB2
D050 8-719-510-02 DIODE D1NS4
D051 6-500-175-01 DIODE 1E3-TB
D052 8-719-109-89 DIODE RD5.6ESB2
D200 8-719-929-15 DIODE HZS9.1NB2
D201 8-719-929-15 DIODE HZS9.1NB2
D202 8-719-929-15 DIODE HZS9.1NB2
D203 8-719-929-15 DIODE HZS9.1NB2
D206 8-719-070-62 DIODE PDZ9.1B-115
(KV-21FA310LN/21FS310LS ONLY)
D207 1-216-864-11 SHORT CHIP
(KV-21FA310LN/21FS310LS ONLY)
D207 8-719-404-50 DIODE MA111-TX
(ALL EXCEPT KV-21FA310LN/21FS310LS)
D208 8-719-929-15 DIODE HZS9.1NB2
(KV-21FA310LN/21FS310LS ONLY)
D209 1-216-864-11 SHORT CHIP
(KV-21FA310LN/21FS310LS ONLY)
D209 8-719-404-50 DIODE MA111-TX
(ALL EXCEPT KV-21FA310LN/21FS310LS)
D230 8-719-108-12 DIODE RD9.1EW
D231 8-719-108-12 DIODE RD9.1EW
(KV-21FA310LN/24FS120/25FS120LN/21FA310LS/25FS120LS ONLY)
D232 8-719-108-12 DIODE RD9.1EW
D234 8-719-108-12 DIODE RD9.1EW
(ALL EXCEPT KV-21FM120)
D235 8-719-108-12 DIODE RD9.1EW
(ALL EXCEPT KV-21FM120)
D236 8-719-108-12 DIODE RD9.1EW
(ALL EXCEPT KV-21FM120)
D237 8-719-108-12 DIODE RD9.1EW
(KV-21FA310LN/24FS120/25FS120LN/21FA310LS/25FS120LS ONLY)
D321 8-719-110-17 DIODE RD10ESB2
D351 8-719-109-66 DIODE RD3.3ESB2
D390 8-719-404-50 DIODE MA111-TX
D401 8-719-921-63 DIODE MTZJ-7.5B
D405 8-719-991-33 DIODE 1SS133T-77
D412 1-216-864-11 SHORT CHIP
D414 8-719-921-63 DIODE MTZJ-7.5B
(KV-21FA310LN/21FA310LS ONLY)
D420 8-719-072-68 DIODE PDZ13B-115
D430 8-719-929-15 DIODE HZS9.1NB2
(ALL EXCEPT KV-21FM120)
D431 8-719-929-15 DIODE HZS9.1NB2
(ALL EXCEPT KV-21FM120)
D432 8-719-108-12 DIODE RD9.1EW
(ALL EXCEPT KV-21FA310LN/21FA310LS)
D500 8-719-404-50 DIODE MA111-TX
D501 8-719-404-50 DIODE MA111-TX
D505 8-719-081-00 DIODE BY228/A52A/
D506 8-719-979-85 DIODE EGP20G
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
D506 6-500-485-01 DIODE FR305G-E
(KV-24FS120/25FS120LN/25FS120LS ONLY)
D507 8-719-991-33 DIODE 1SS133T-77
D508 8-719-404-50 DIODE MA111-TX
D513 8-719-404-50 DIODE MA111-TX
D514 8-719-908-03 DIODE GP08D
D515 8-719-908-03 DIODE GP08D
D525 8-719-991-33 DIODE 1SS133T-77
D526 8-719-074-25 DIODE PG104R
D528 8-719-991-33 DIODE 1SS133T-77
A
