65
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
D545 8-719-908-03 DIODE GP08D
D558 8-719-404-50 DIODE MA111-TX
D559 8-719-404-50 DIODE MA111-TX
D562 8-719-991-33 DIODE 1SS133T-77
D566 8-719-979-84 DIODE EGP20DPKG23
D567 8-719-991-33 DIODE 1SS133T-77
D568 8-719-110-08 DIODE RD8.2ESB2
D569 8-719-921-44 DIODE MTZJ-5.1C
D587 8-719-074-25 DIODE PG104R
D589 8-719-991-33 DIODE 1SS133T-77
D596 8-719-063-70 DIODE D1NL20U
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
D596 6-500-531-01 DIODE PG154R
(KV-24FS120/25FS120LN/25FS120LS ONLY)
D598 8-719-063-70 DIODE D1NL20U
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
D598 6-500-531-01 DIODE PG154R
(KV-24FS120/25FS120LN/25FS120LS ONLY)
D603 8-719-064-12 DIODE S1NB60-4062
D604 6-500-890-01 DIODE 1N5406G-EB
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
D605 8-719-510-53 DIODE D4SB60L
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
D606 6-500-890-01 DIODE 1N5406G-EB
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
D611 8-719-510-73 DIODE S3L20µF4
D612 8-719-068-00 DIODE ERC04-06SE
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
D613 8-719-068-00 DIODE ERC04-06SE
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
D614 8-719-057-52 DIODE EZ0150AV1
D615 6-500-177-01 DIODE MA7D50
D618 8-719-979-64 DIODE µF4005PKG23
D620 8-719-911-19 DIODE 1SS119-25
D621 8-719-510-37 DIODE D5LC20U
D624 8-719-510-73 DIODE S3L20µF4
D628 8-719-404-50 DIODE MA111-TX
D629 8-719-110-31 DIODE RD12ESB2
D631 6-500-175-01 DIODE 1E3-TB
D641 8-719-991-33 DIODE 1SS133T-77
D642 8-719-982-22 DIODE MTZJ-30D
D644 8-719-110-31 DIODE RD12ESB2
D645 8-719-109-89 DIODE RD5.6ESB2
D650 8-719-109-89 DIODE RD5.6ESB2
FUSE
!
F601 1-576-193-11 FUSE 6.3A 125V
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
!
F601 1-532-506-51 FUSE 6.3A 250V
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
FERRITE BEAD
FB301 1-410-397-21 FERRITE 1.1µH
FB505 1-410-397-21 FERRITE 1.1µH
FB506 1-410-397-21 FERRITE 1.1µH
FB522 1-410-397-21 FERRITE 1.1µH
FB601 1-410-397-21 FERRITE 1.1µH
FB602 1-410-397-21 FERRITE 1.1µH
FB603 1-410-397-21 FERRITE 1.1µH
FB604 1-410-397-21 FERRITE 1.1µH
FB605 1-410-397-21 FERRITE 1.1µH
FB616 1-469-578-11 FERRITE 1.1µH
FB617 1-469-578-11 FERRITE 1.1µH
FILTER
FL001 1-239-803-11 ENCAPSULATED COMPONENT
IC
!
IC001 6-804-178-01 IC M65582AµF-XXXFP
IC002 6-704-004-01 IC BR24L16F-WE2
IC003 8-759-352-91 IC PST9143NL
IC321 8-759-353-00 IC NJM2534M(TE2)
IC400 6-706-033-01 IC NJW1172JK1-TE2
(KV-21FA310LN/21FA310LS ONLY)
IC401 6-706-032-01 IC NJW1142M(TE2)
(ALL EXCEPT KV-21FA310LN/21FA310LS ONLY)
IC404 6-705-054-01 IC TDA8947J
IC545 6-703-470-01 IC STV9302A
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
IC545 8-759-696-71 IC STV9379A
(KV-24FS120/25FS120LN/25FS120LS ONLY)
!
IC561 8-759-700-07 IC NJM2903M
IC565 8-759-700-44 IC NJM2902M
IC600 6-705-810-01 IC MCZ3001DB
IC603 6-705-466-01 IC BA90BC0T
(KV-21FA310LN/21FA310LS ONLY)
IC603 6-705-818-01 IC MC7809CF
(ALL EXCEPT KV-21FA310LN/21FA310LS)
A
