Sony TRINITRON KV-21FA310 - Page 66

66
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
! IC604 8-749-012-13 IC DM-58
IC608 8-759-450-47 IC BA05T
IC633 6-703-080-01 IC LF33CV
JACK
J200 1-794-115-11 JACK BLOCK 2P
(KV-21FM120 ONLY)
J200 1-794-118-11 JACK BLOCK 3P
(KV-20FS120/21FS120LN/21FS120LS ONLY)
J200 1-794-119-11 TERMINAL BLOCK, S 4P
(KV-21FA310LN/24FS120/25FS120LN/21FA310LS/25FS120LS ONLY)
J201 1-794-048-11 JACK, PIN 3P
(KV-21FA310LN/21FA310LS ONLY)
* J203 1-817-461-11 PIN JACK BLOCK 5P
(ALL EXCEPT KV-21FM120)
* J205 1-818-352-11 PIN JACK W/DIN CONNECTOR
(KV-21FA310LN/21FA310LS ONLY)
J401 1-750-264-11 JACK
(KV-21FA310LN/21FA310LS ONLY)
CHIP CONDUCTOR
JR2 1-216-864-11 SHORT CHIP
JR6 1-216-864-11 SHORT CHIP
JR7 1-216-864-11 SHORT CHIP
JR12 1-216-864-11 SHORT CHIP
JR44 1-216-864-11 SHORT CHIP
JR102 1-216-864-11 SHORT CHIP
JR128 1-216-864-11 SHORT CHIP
JR201 1-216-864-11 SHORT CHIP
JR207 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-21FM120)
JR209 1-216-864-11 SHORT CHIP
JR211 1-216-864-11 SHORT CHIP
JR212 1-216-864-11 SHORT CHIP
JR213 1-216-864-11 SHORT CHIP
JR214 1-216-864-11 SHORT CHIP
JR215 1-216-864-11 SHORT CHIP
JR255 1-216-864-11 SHORT CHIP
JR301 1-216-864-11 SHORT CHIP
JR302 1-216-864-11 SHORT CHIP
JR303 1-216-864-11 SHORT CHIP
JR304 1-216-864-11 SHORT CHIP
JR305 1-216-864-11 SHORT CHIP
JR306 1-216-864-11 SHORT CHIP
JR310 1-216-864-11 SHORT CHIP
JR311 1-216-864-11 SHORT CHIP
JR312 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-21FM120)
JR315 1-216-864-11 SHORT CHIP
JR317 1-216-864-11 SHORT CHIP
JR401 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-21FM120)
JR402 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-21FM120)
JR403 1-216-864-11 SHORT CHIP
(ALL EXCEPT KV-21FM120)
JR411 1-216-864-11 SHORT CHIP
JR485 1-216-864-11 SHORT CHIP
JR486 1-216-864-11 SHORT CHIP
JR504 1-216-864-11 SHORT CHIP
JR585 1-216-864-11 SHORT CHIP
JR586 1-216-864-11 SHORT CHIP
JR1502 1-216-864-11 SHORT CHIP
JUMPER WIRE
JW57 1-249-409-11 CARBON 220 5% 1/4W
COIL
L002 1-239-803-11 ENCAPSULATED COMPONENT
L003 1-239-803-11 ENCAPSULATED COMPONENT
L004 1-239-803-11 ENCAPSULATED COMPONENT
L005 1-239-803-11 ENCAPSULATED COMPONENT
L006 1-414-273-11 INDUCTOR 100µH
L007 1-414-273-11 INDUCTOR 100µH
L008 1-414-857-11 INDUCTOR 100µH
L009 1-414-857-11 INDUCTOR 100µH
L010 1-414-267-21 INDUCTOR 10µH
L011 1-239-803-11 ENCAPSULATED COMPONENT
L101 1-414-229-11 FERRITE 0µH
! L510 1-406-981-21 INDUCTOR 470µH
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
L513 1-406-677-11 INDUCTOR 10MH
L515 1-412-552-11 INDUCTOR 2.2MH
A
