KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
L516 1-406-978-11 INDUCTOR 150µH
(KV-24FS120/25FS120LN/25FS120LS ONLY)
L525 1-409-955-31 INDUCTOR 8MH
L527 1-410-397-21 FERRITE 1.1µH
L588 1-412-528-11 INDUCTOR 18µH
L606 1-412-525-31 INDUCTOR 10µH
L607 1-412-525-31 INDUCTOR 10µH
L608 1-412-533-21 INDUCTOR 47µH
L609 1-412-525-31 INDUCTOR 10µH
PHOTO COUPLER
! PH602 8-749-010-64 PHOTO COUPLER PC123F2
IC LINK
PS401 1-576-337-21 IC LINK 2.7A 50V
TRANSISTOR
Q002 8-729-422-27 TRANSISTOR 2SD601A-Q
Q004 8-729-422-27 TRANSISTOR 2SD601A-Q
Q005 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q006 8-729-422-27 TRANSISTOR 2SD601A-Q
Q008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q009 8-729-422-27 TRANSISTOR 2SD601A-Q
Q300 8-729-422-27 TRANSISTOR 2SD601A-Q
Q301 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q304 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q305 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q306 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q316 8-729-422-27 TRANSISTOR 2SD601A-Q
Q390 8-729-422-27 TRANSISTOR 2SD601A-Q
Q391 8-729-422-27 TRANSISTOR 2SD601A-Q
Q400 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-21FA310LN/21FA310LS ONLY)
Q401 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-21FA310LN/21FA310LS ONLY)
Q403 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-21FA310LN/21FA310LS ONLY)
Q404 8-729-422-27 TRANSISTOR 2SD601A-Q
Q411 8-729-422-27 TRANSISTOR 2SD601A-Q
Q412 8-729-422-27 TRANSISTOR 2SD601A-Q
(KV-21FA310LN/21FA310LS ONLY)
Q420 8-729-422-27 TRANSISTOR 2SD601A-Q
Q421 8-729-422-27 TRANSISTOR 2SD601A-Q
Q501 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q502 8-729-140-50 TRANSISTOR 2SC3209LK
Q503 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q504 8-729-422-27 TRANSISTOR 2SD601A-Q
Q505 6-550-041-01 TRANSISTOR 2SD2634-Y
(KV-24FS120/25FS120LN/25FS120LS ONLY)
! Q506 6-550-042-01 TRANSISTOR 2SD2627LS-YB11
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
Q519 8-729-422-27 TRANSISTOR 2SD601A-Q
Q521 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q522 8-729-053-87 TRANSISTOR KTC4370A
Q531 8-729-422-27 TRANSISTOR 2SD601A-Q
Q533 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q572 8-729-422-27 TRANSISTOR 2SD601A-Q
Q573 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q578 8-729-422-27 TRANSISTOR 2SD601A-Q
Q590 6-550-362-01 TRANSISTOR KTA1279
Q600 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
(ALL EXCEPT KV-21FM120)
Q600 8-729-052-29 TRANSISTOR 2SK2876-01MR-F122
(KV-21FM120 ONLY)
Q601 8-729-053-36 TRANSISTOR 2SK2640-01MR-F122
(ALL EXCEPT KV-21FM120)
Q601 8-729-052-29 TRANSISTOR 2SK2876-01MR-F122
(KV-21FM120 ONLY)
Q604 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q608 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q650 6-550-409-01 TRANSISTOR KSC2383-O
Q860 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R002 1-216-864-11 SHORT CHIP
R003 1-216-821-11 METAL CHIP 1K 5% 1/10W
R004 1-216-817-11 METAL CHIP 470 5% 1/10W
R005 1-400-427-21 FERRITE 0µH
R006 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R007 1-400-427-21 FERRITE 0µH
R015 1-216-833-11 METAL CHIP 10K 5% 1/10W
R027 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
