KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
R802 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
(KV-24FS120/25FS120LN/25FS120LS ONLY)
R803 1-218-719-11 METAL CHIP 13K 0.50% 1/10W
R804 1-249-435-11 CARBON 33K 5% 1/4W
R812 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R813 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R814 1-218-736-11 METAL CHIP 68K 0.50% 1/10W
R815 1-218-732-11 METAL CHIP 47K 0.50% 1/10W
R850 1-215-453-00 METAL 22K 1% 1/4W
R851 1-216-821-11 METAL CHIP 1K 5% 1/10W
R852 1-218-869-11 METAL CHIP 8.2K 0.50% 1/10W
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
R860 1-216-833-11 METAL CHIP 10K 5% 1/10W
R861 1-216-833-11 METAL CHIP 10K 5% 1/10W
R862 1-216-813-11 METAL CHIP 220 5% 1/10W
R893 1-216-864-11 SHORT CHIP
RELAY
RY501 1-755-198-11 RELAY, AC POWER
! RY600 1-755-395-11 RELAY (AC POWER)
SWITCH
S002 1-692-431-21 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S003 1-692-431-21 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S004 1-692-431-21 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S005 1-692-431-21 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S006 1-692-431-21 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S007 1-762-816-11 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
S008 1-762-816-11 SWITCH, TACTILE
(KV-21FA310LN/21FA310LS ONLY)
SW515 1-572-707-11 SWITCH, LEVER
TRANSFORMER
T505 1-433-836-11 TRANSFORMER, HORIZONTAL DRIVE
T510 1-437-610-11 TRANSFORMER, FERRITE
(KV-24FS120/25FS120LN/25FS120LS ONLY)
! T511 1-435-079-21 TRANSFORMER, HORIZONTAL LINEAR
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
! T511 1-433-850-11 TRANSFORMER, HORIZONTAL LINEAR
(KV-24FS120/25FS120LN/25FS120LS ONLY)
! T585 1-453-316-21 FBT ASSY NX-1748//X4A4
(ALL EXCEPT KV-24FS120/25FS120LN/25FS120LS)
! T585 1-453-336-11 FBT ASSY NX-4011//X4A4
(KV-24FS120/25FS120LN/25FS120LS ONLY)
! T601 1-435-617-11 TRANSFORMER, LINE FILTER
! T602 1-435-675-11 TRANSFORMER, STANDBY
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
! T602 1-435-676-11 TRANSFORMER, STANDBY
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
! T603 1-439-898-21 CONVERTER TRANSFORMER
(ALL EXCEPT KV-21FM120)
! T603 1-437-609-11 CONVERTER TRANSFORMER
(KV-21FM120 ONLY)
THERMISTOR
! THP501 1-809-539-11 THERMISTOR, POSITIVE
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
! THP501 1-809-540-11 THERMISTOR, POSITIVE
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
TUNER
! TU101 8-598-593-50 TUNER, FSS BTF-WA421
(ALL EXCEPT KV-21FM120)
! TU101 8-598-594-30 TUNER, FSS BTF-FA421
(KV-21FM120 ONLY)
VARISTOR
! VDR600 1-810-974-21 VARISTOR
(ALL EXCEPT KV-21FA310LS/21FS120LS/25FS120LS)
! VDR600 1-803-967-11 VARISTOR
(KV-21FA310LS/21FS120LS/25FS120LS ONLY)
CRYSTAL
X001 1-795-006-21 VIBRATOR, CRYSTAL
X301 1-781-377-21 VIBRATOR, CRYSTAL
