74
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
CV
* A-1410-919-A CV (VAR) BOARD, MOUNTED
(KV-20FS120/21FA310LN/21FA310LS/21FM120/21FS120LN/21FS120LS ONLY)
* A-1415-605-A CV (VAR) BOARD, MOUNTED
(KV-24FS120/25FS120LN/25FS120LS ONLY)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C901 1-107-667-11 ELECT 2.2µF 20% 400V
C902 1-130-491-00 MYLAR 0.047µF 5% 50V
C903 1-126-935-11 ELECT 470µF 20% 16V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-106-383-00 MYLAR 0.047µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-638-11 ELECT 33µF 20% 160V
C908 1-126-935-11 ELECT 470µF 20% 16V
C909 1-161-830-00 CERAMIC 0.0047µF 500V
C910 1-104-999-11 MYLAR 0.1µF 5% 200V
C911 1-104-665-11 ELECT 100µF 20% 25V
C912 1-126-942-61 ELECT 1000µF 20% 25V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
C915 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C1751 1-107-652-11 ELECT 10µF 20% 250V
C1752 1-162-114-00 CERAMIC 0.0047µF 2KV
C1753 1-137-528-11 MYLAR 0.1µF 10% 250V
C1754 1-102-074-00 CERAMIC 0.001µF 10% 50V
C1755 1-107-649-11 ELECT 2.2µF 20% 250V
C1774 1-126-960-11 ELECT 1µF 20% 50V
C1775 1-126-935-11 ELECT 470µF 20% 16V
C1777 1-126-963-11 ELECT 4.7µF 20% 50V
C1778 1-126-947-11 ELECT 47µF 20% 35V
CONNECTOR
* CN903 1-564-506-11 PLUG, CONNECTOR 3P
CN1707 1-564-506-11 PLUG, CONNECTOR 3P
* CN1752 1-564-512-11 PLUG, CONNECTOR 9P
CN1753 1-785-879-11 CONNECTOR, ONE TOUCH
CN1755 1-695-915-11 TAB (CONTACT)
DIODE
D762 8-719-404-50 DIODE MA111-TX
D763 8-719-404-50 DIODE MA111-TX
D772 8-719-404-50 DIODE MA111-TX
D773 8-719-404-50 DIODE MA111-TX
D782 8-719-404-50 DIODE MA111-TX
D783 8-719-404-50 DIODE MA111-TX
D901 8-719-110-86 DIODE RD39ESB
D902 8-719-110-86 DIODE RD39ESB
D903 8-719-991-33 DIODE 1SS133T-77
D1701 8-719-108-12 DIODE RD9.1EW
D1754 8-719-901-83 DIODE 1SS83
D1755 8-719-901-83 DIODE 1SS83
D1756 8-719-901-83 DIODE 1SS83
D1758 8-719-074-25 DIODE PG104R
IC
IC1707 8-759-356-16 IC NJM4556AD
IC1751 8-759-562-43 IC TDA6108JF/N1B
JACK
!
J1751 1-451-544-11 SOCKET, CRT
CHIP CONDUCTOR
JR710 1-216-864-11 SHORT CHIP
COIL
L901 1-408-615-31 INDUCTOR 100µH
L1751 1-408-613-31 INDUCTOR 68µH
TRANSISTOR
Q761 8-729-422-27 TRANSISTOR 2SD601A-Q
Q762 8-729-422-27 TRANSISTOR 2SD601A-Q
Q763 8-729-422-27 TRANSISTOR 2SD601A-Q
Q771 8-729-422-27 TRANSISTOR 2SD601A-Q
Q772 8-729-422-27 TRANSISTOR 2SD601A-Q
Q773 8-729-422-27 TRANSISTOR 2SD601A-Q
Q781 8-729-422-27 TRANSISTOR 2SD601A-Q
Q782 8-729-422-27 TRANSISTOR 2SD601A-Q
CV
