75
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
KV-20FS120/21FM120/21FS120/21FA310/24FS120/25FS120
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
Q783 8-729-422-27 TRANSISTOR 2SD601A-Q
Q901 8-729-053-87 TRANSISTOR KTC4370A
Q902 6-550-247-01 TRANSISTOR KTA1659A
Q903 8-729-422-27 TRANSISTOR 2SD601A-Q
Q904 8-729-422-27 TRANSISTOR 2SD601A-Q
Q905 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q906 8-729-422-27 TRANSISTOR 2SD601A-Q
Q1772 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R760 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R762 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R763 1-216-835-11 METAL CHIP 15K 5% 1/10W
R764 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R765 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R766 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R767 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R768 1-216-821-11 METAL CHIP 1K 5% 1/10W
R770 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R772 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R773 1-216-835-11 METAL CHIP 15K 5% 1/10W
R774 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R775 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R776 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R777 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R778 1-216-821-11 METAL CHIP 1K 5% 1/10W
R780 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R782 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R783 1-216-835-11 METAL CHIP 15K 5% 1/10W
R784 1-218-678-11 METAL CHIP 270 0.50% 1/10W
R785 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R786 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R787 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R788 1-216-821-11 METAL CHIP 1K 5% 1/10W
R901 1-249-401-11 CARBON 47 5% 1/4W
R902 1-249-386-11 CARBON 2.7 5% 1/4W
R903 1-249-414-11 CARBON 560 5% 1/4W
R904 1-249-432-11 CARBON 18K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W
R906 1-249-432-11 CARBON 18K 5% 1/4W
R907 1-249-386-11 CARBON 2.7 5% 1/4W
R908 1-249-414-11 CARBON 560 5% 1/4W
R909 1-260-312-11 CARBON 47 5% 1/2W
R910 1-216-476-11 METAL OXIDE 180 5% 3W
R911 1-216-799-11 METAL CHIP 15 5% 1/10W
R912 1-216-813-11 METAL CHIP 220 5% 1/10W
R913 1-216-799-11 METAL CHIP 15 5% 1/10W
R914 1-216-814-11 METAL CHIP 270 5% 1/10W
R915 1-216-821-11 METAL CHIP 1K 5% 1/10W
R916 1-216-821-11 METAL CHIP 1K 5% 1/10W
R917 1-216-821-11 METAL CHIP 1K 5% 1/10W
R918 1-216-809-11 METAL CHIP 100 5% 1/10W
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-820-11 METAL CHIP 820 5% 1/10W
R921 1-216-833-11 METAL CHIP 10K 5% 1/10W
R922 1-249-397-11 CARBON 22 5% 1/4W
R923 1-249-401-11 CARBON 47 5% 1/4W
R1756 1-260-328-11 CARBON 1K 5% 1/2W
R1757 1-260-328-11 CARBON 1K 5% 1/2W
R1758 1-260-328-11 CARBON 1K 5% 1/2W
R1760 1-260-123-11 CARBON 100K 5% 1/2W
R1761 1-216-373-11 METAL OXIDE 2.2 5% 2W
R1761 1-216-395-00 METAL OXIDE 3.3 5% 3W
(KV-20FS120/21FA310LN/21FA310LS/21FM120/21FS120LN/21FS120LS ONLY)
R1761 1-216-373-11 METAL OXIDE 2.2 2W
(KV-24FS120/25FS120LN/25FS120LS ONLY)
R1762 1-216-375-00 METAL OXIDE 3.3 5% 2W
(KV-24FS120/25FS120LN/25FS120LS ONLY)
R1763 1-247-807-31 CARBON 100 5% 1/4W
R1764 1-247-807-31 CARBON 100 5% 1/4W
R1765 1-247-807-31 CARBON 100 5% 1/4W
R1766 1-247-807-31 CARBON 100 5% 1/4W
R1767 1-247-807-31 CARBON 100 5% 1/4W
R1768 1-247-807-31 CARBON 100 5% 1/4W
R1770 1-260-132-11 CARBON 560K 5% 1/2W
R1778 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1779 1-247-791-91 CARBON 22 5% 1/4W
(KV-24FS120/25FS120LN/25FS120LS ONLY)
R1780 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1781 1-216-838-11 METAL CHIP 27K 5% 1/10W
R1785 1-249-399-11 CARBON 33 5% 1/4W
R1787 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1788 1-249-421-11 CARBON 2.2K 5% 1/4W
R1789 1-249-425-11 CARBON 4.7K 5% 1/4W
VARIABLE RESISTOR
RV1701 1-238-019-11 RES, ADJ, METAL FILM 47K
!
RV1750 1-241-656-11 RES, ADJ, METAL FILM 110M
CV
