Sony Trinitron KV-25M2A - A Board; 7 Electrical Parts List

43
KV-25M2/25T2
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
• Items marked “ * “ are not stocked since
they are seldom required for routine serv-
ice. Some delay should be anticipated
when ordering these items.
•
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• RESISTORS
• All resistors are in ohms.
• F : nonflammable.
When indicating parts by reference number,
please include the board name.
CAPACITORS COILS
MF : mF, PF : mmF MMH : mH , uH
A
*A-1632-761-A A BOARD COMPLETE (KV-25M2A)
****************
*A-1632-762-A A BOARD COMPLETE (KV-25T2A)
****************
*A-1632-788-A A BOARD COMPLETE (KV-25T2B)
****************
*A-1632-756-A A BOARD COMPLETE (KV-25M2D)
****************
*A-1632-755-A A BOARD COMPLETE (KV-25T2D)
****************
*A-1632-758-A A BOARD COMPLETE (KV-25M2E)
****************
*A-1632-754-A A BOARD COMPLETE (KV-25T2E)
****************
*A-1632-767-A A BOARD COMPLETE (KV-25M2K)
****************
*A-1632-766-A A BOARD COMPLETE (KV-25T2K)
****************
*A-1632-765-A A BOARD COMPLETE (KV-25T2L)
****************
*A-1632-764-A A BOARD COMPLETE (KV-25T2R)
****************
*A-1632-763-A A BOARD COMPLETE (KV-25T2U)
****************
4-382-854-11 SCREW (M3X10), P, SW (+)
< CAPACITOR >
C001 1-104-665-11 ELECT 100MF 20% 25V
C002 1-126-965-11 ELECT 22MF 20% 50V
C004 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C005 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C006 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C007 1-126-935-11 ELECT 470MF 20% 16V
C008 1-126-964-11 ELECT 10MF 20% 50V
C009 1-126-965-11 ELECT 22MF 20% 50V
C011 1-126-965-11 ELECT 22MF 20% 50V
C012 1-126-959-11 ELECT 0.47MF 20% 50V
C013 1-163-017-91 CERAMIC CHIP 4700PF 10% 50V
C016 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C018 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C019 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C022 1-126-935-11 ELECT 470MF 20% 16V
C024 1-126-964-11 ELECT 10MF 20% 50V
C025 1-126-960-11 ELECT 1MF 20% 50V
C029 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V
C030 1-126-923-91 ELECT 220MF 20% 10V
C031 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C032 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C035 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C036 1-163-017-91 CERAMIC CHIP 4700PF 10% 50V
C037 1-163-017-91 CERAMIC CHIP 4700PF 10% 50V
C038 1-126-964-11 ELECT 10MF 20% 50V
C039 1-163-017-91 CERAMIC CHIP 4700PF 10% 50V
C040 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C041 1-163-205-00 CERAMIC CHIP 0.001MF 10% 50V
C042 1-126-933-11 ELECT 100MF 20% 16V
C043 1-126-935-11 ELECT 470MF 20% 16V
C100 1-163-031-11 CERAMIC CHIP 0.01MF 50V
(KV-25T2B)
C101 1-164-665-11 CERAMIC CHIP 0.039MF 10% 50V
C102 1-164-665-11 CERAMIC CHIP 0.039MF 10% 50V
C103 1-104-665-11 ELECT 100MF 20% 25V
C105 1-126-965-11 ELECT 22MF 20% 50V
C106 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C107 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C108 1-163-465-11 CERAMIC CHIP 9PF 0.25PF 50V
C109 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C110 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C111 1-163-059-00 CERAMIC CHIP 0.01MF 50V
C112 1-163-031-11 CERAMIC CHIP 0.01MF 50V
C113 1-126-965-11 ELECT 22MF 20% 50V
C114 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
