52
KV-25M2/25T2
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D714 8-719-991-33 DIODE 1SS133T-77
D715 8-719-991-33 DIODE 1SS133T-77
D716 8-719-991-33 DIODE 1SS133T-77
D717 8-719-991-33 DIODE 1SS133T-77
D718 8-719-991-33 DIODE 1SS133T-77
D719 8-719-991-33 DIODE 1SS133T-77
< CRT SOCKET >
J701 £ 1-526-990-21 SOCKET, CRT
< COIL >
L704 1-408-609-41 INDUCTOR 33UH
< TRANSISTOR >
Q702 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q703 8-729-906-70 TRANSISTOR BF871-127
Q704 8-729-200-17 TRANSISTOR BF421L-AMMO
Q705 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q706 8-729-906-70 TRANSISTOR BF871-127
Q707 8-729-200-17 TRANSISTOR BF421L-AMMO
Q708 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q709 8-729-906-70 TRANSISTOR BF871-127
Q710 8-729-200-17 TRANSISTOR BF421L-AMMO
< RESISTOR >
R701 1-247-895-91 CARBON 470K 5% 1/4W
R704 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R705 1-260-103-11 CARBON 2.2K 5% 1/2W
R706 1-247-815-91 CARBON 220 5% 1/4W
R707 1-247-815-91 CARBON 220 5% 1/4W
R708 1-247-791-91 CARBON 22 5% 1/4W
R709 1-202-844-00 SOLID 330K 10% 1/2W
R711 1-247-843-11 CARBON 3.3K 5% 1/4W
R712 1-260-103-11 CARBON 2.2K 5% 1/2W
R713 1-249-439-11 CARBON 68K 5% 1/4W
R714 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R715 1-249-417-11 CARBON 1K 5% 1/4W
R716 1-247-815-91 CARBON 220 5% 1/4W
R717 1-247-815-91 CARBON 220 5% 1/4W
R718 1-202-814-11 SOLID 33K 10% 1/2W
R719 1-247-791-91 CARBON 22 5% 1/4W
R720 1-247-843-11 CARBON 3.3K 5% 1/4W
R722 1-202-848-00 SOLID 680K 10% 1/2W
R723 1-249-417-11 CARBON 1K 5% 1/4W
R724 1-260-131-11 CARBON 470K 5% 1/2W
R726 1-260-103-11 CARBON 2.2K 5% 1/2W
R727 1-247-815-91 CARBON 220 5% 1/4W
R728 1-216-351-00 METAL OXIDE 1.5 5% 1W F
R729 1-247-815-91 CARBON 220 5% 1/4W
R730 1-247-791-91 CARBON 22 5% 1/4W
R731 1-247-843-11 CARBON 3.3K 5% 1/4W
R733 1-249-413-11 CARBON 470 5% 1/4W
R734 1-247-807-31 CARBON 100 5% 1/4W
R735 1-249-413-11 CARBON 470 5% 1/4W
R736 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R737 1-247-891-00 CARBON 330K 5% 1/4W
R739 1-249-417-11 CARBON 1K 5% 1/4W
R740 1-249-413-11 CARBON 470 5% 1/4W
R741 1-202-549-00 SOLID 100 20% 1/2W
R744 1-249-421-11 CARBON 2.2K 5% 1/4W
R745 1-249-421-11 CARBON 2.2K 5% 1/4W
R746 1-249-421-11 CARBON 2.2K 5% 1/4W
< VARIABLE RESISTOR >
RV701 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV702 1-241-656-21 RES, ADJ, METAL FILM 110M
**************************************************************
