53
KV-25M2/25T2
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
MISCELLANEOUS
*************
£ 1-416-465-21 COIL, DEMAGNETIC
1-452-032-00 MAGNET, DISC; 10MM Ø
1-452-094-00 MAGNET, ROTATABLE DISK; 15MM Ø
£ 1-453-264-11 TRANSFORMER ASSY, FLYBACK (NX-1680/U2B4)
1-504-698-11 SPEAKER (5X9CM)
£ 1-251-317-31 CAP ASSY, HIGH-VOLTAGE
£ 1-571-433-21 SWITCH, PUSH (AC POWER)
£ 1-765-286-11 CORD POWER
(KV-25M2A/25T2A/25T2B/25M2D/25T2D/
KV-25M2E/25T2E/25M2K/25T2K)
£ 1-776-860-11 POWER CORD, FILTER (UK) (KV-25T2L/25T2U)
£ 1-690-270-21 CORD, POWER (WITH CONNECTOR) (KV-25T2R)
8-598-331-02 TUNER (VSS BT-AC401)
(KV-25M2A/25T2A/25M2D/25T2D/25M2E/25T2E/
KV-25M2K/25T2K/25T2L/25T2R/25T2U)
1-693-310-11 TUNER (TELE-002B) (KV-25T2B)
£ 8-451-404-23 DEFLECTION YOKE (Y25GXABA)
£ 8-733-254-05 PICTURE TUBE (SD-257) (M60LCS60X)
**************************************************************
ACCESSORIES AND PACKAGING MATERIAL
**********************************
4-204-210-41 MANUAL, INSTRUCTION (KV-25M2A/25T2A)
(ITALIAN)
4-204-210-51 MANUAL, INSTRUCTION (KV-25T2B)
(FRENCH/ITALIAN/GERMAN/DUTCH)
4-204-209-11 MANUAL, INSTRUCTION (KV-25M2D/25T2D)
(ENGLISH/GERMAN/GREEK/DUTCH/TURKISH)
4-204-210-11 MANUAL, INSTRUCTION (KV-25M2D/25T2D)
(GERMAN/ENGLISH)
4-204-210-71 MANUAL, INSTRUCTION (KV-25M2E/25T2E)
(SPANISH)
4-204-210-81 MANUAL, INSTRUCTION (KV-25M2E/25T2E)
(PORTUGUESE/FINNISH/DANISH/NORWEGIAN/SWEDISH)
4-204-210-91 MANUAL, INSTRUCTION (KV-25M2K/25T2K/25T2R)
(HUNGARIAN/POLISH/CZECH/ENGLISH/
RUSSIAN/BULGARIAN)
4-204-209-61 MANUAL, INSTRUCTION (KV-25T2L/25T2U)
(ENGLISH)
*4-042-476-01 BAG, PROTECTION
*4-204-218-01 INDIVIDUAL CARTON
*4-203-271-01 CUSHION (LOWER) (ASSY)
*4-203-268-01 CUSHION (UPPER) (ASSY)
REMOTE COMMANDER
****************
1-475-765-11 COMMANDER, STANDARD TYPE (RM-883)
**************************************************************
