Sony Trinitron KV-25M2A - Page 37

49
KV-25M2/25T2
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R101 1-216-049-00 RES,CHIP 1K 5% 1/10W
R102 1-216-109-00 RES,CHIP 330K 5% 1/10W
R104 1-216-081-00 RES,CHIP 22K 5% 1/10W
R105 1-216-081-00 RES,CHIP 22K 5% 1/10W
R106 1-215-900-11 METAL OXIDE 22K 5% 2W F
R107 1-216-230-00 RES,CHIP 22K 5% 1/8W
R108 1-216-081-00 RES,CHIP 22K 5% 1/10W
R109 1-216-073-00 RES,CHIP 10K 5% 1/10W
R110 1-216-206-00 RES,CHIP 2.2K 5% 1/8W (KV-25T2B)
R111 1-216-057-00 RES,CHIP 2.2K 5% 1/10W (KV-25T2B)
R112 1-216-057-00 RES,CHIP 2.2K 5% 1/10W (KV-25T2B)
R113 1-216-049-00 RES,CHIP 1K 5% 1/10W
R114 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
(KV-25M2K/25T2K/25T2R)
R115 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
(KV-25M2K/25T2K/25T2R)
R117 1-216-049-00 RES,CHIP 1K 5% 1/10W
R118 1-216-295-00 SHORT 0
R119 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R120 1-216-037-00 RES,CHIP 330 5% 1/10W
R123 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R124 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R125 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R127 1-216-031-00 RES,CHIP 180 5% 1/10W (KV-25T2B)
R128 1-216-065-00 RES,CHIP 4.7K 5% 1/10W (KV-25T2B)
R129 1-216-063-91 RES,CHIP 3.9K 5% 1/10W (KV-25T2B)
R131 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R132 1-216-295-00 SHORT 0
(KV-25M2A/25T2A/25M2D/25T2D/25M2E/25T2E/
KV-25M2K/25T2K/25T2L/25T2R/25T2U)
R133 1-216-295-00 SHORT 0
(KV-25M2A/25T2A/25M2D/25T2D/25M2E/25T2E/
KV-25M2K/25T2K/25T2L/25T2R/25T2U)
R135 1-216-043-91 RES,CHIP 560 5% 1/10W
(KV-25M2K/25T2K/25T2R)
R136 1-216-043-91 RES,CHIP 560 5% 1/10W
R142 1-216-295-00 SHORT 0
R143 1-216-027-00 RES,CHIP 120 5% 1/10W
R144 1-216-079-00 RES,CHIP 18K 5% 1/10W
R145 1-216-212-00 RES,CHIP 3.9K 5% 1/8W
R147 1-216-017-91 RES,CHIP 47 5% 1/10W (KV-25T2B)
R148 1-216-174-00 RES,CHIP 100 5% 1/8W (KV-25T2B)
R149 1-216-049-00 RES,CHIP 1K 5% 1/10W (KV-25T2B)
R150 1-216-025-00 RES,CHIP 100 5% 1/10W
(KV-25M2K/25T2K/25T2R)
R151 1-216-049-00 RES,CHIP 1K 5% 1/10W
R152 1-216-025-00 RES,CHIP 100 5% 1/10W (KV-25T2B)
R153 1-216-180-00 RES,CHIP 180 5% 1/8W (KV-25T2B)
R154 1-216-238-91 RES,CHIP 47K 5% 1/8W
R155 1-216-089-00 RES,CHIP 47K 5% 1/10W
R156 1-216-073-00 RES,CHIP 10K 5% 1/10W (KV-25T2B)
R157 1-216-063-91 RES,CHIP 3.9K 5% 1/10W (KV-25T2B)
R158 1-216-069-00 RES,CHIP 6.8K 5% 1/10W (KV-25T2B)
R201 1-216-033-00 RES,CHIP 220 5% 1/10W
R204 1-247-863-91 CARBON 22K 5% 1/4W
R205 1-216-033-00 RES,CHIP 220 5% 1/10W
R206 1-216-085-00 RES,CHIP 33K 5% 1/10W
R209 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R211 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
R301 1-216-025-00 RES,CHIP 100 5% 1/10W
R302 1-216-081-00 RES,CHIP 22K 5% 1/10W
R303 1-216-073-00 RES,CHIP 10K 5% 1/10W
R304 1-216-073-00 RES,CHIP 10K 5% 1/10W
R306 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R309 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R310 1-216-022-00 RES,CHIP 75 5% 1/10W
R311 1-216-022-00 RES,CHIP 75 5% 1/10W
R313 1-216-025-00 RES,CHIP 100 5% 1/10W
R314 1-216-025-00 RES,CHIP 100 5% 1/10W
R315 1-216-075-91 RES,CHIP 12K 5% 1/10W
R316 1-216-025-00 RES,CHIP 100 5% 1/10W
R317 1-216-049-00 RES,CHIP 1K 5% 1/10W
R318 1-216-025-00 RES,CHIP 100 5% 1/10W
R319 1-216-025-00 RES,CHIP 100 5% 1/10W
R320 1-216-025-00 RES,CHIP 100 5% 1/10W
R321 1-216-025-00 RES,CHIP 100 5% 1/10W
R323 1-216-025-00 RES,CHIP 100 5% 1/10W
R324 1-412-002-21 INDUCTOR CHIP 4.7UH
R325 1-412-002-21 INDUCTOR CHIP 4.7UH
R326 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R331 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R332 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R333 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R334 1-216-025-00 RES,CHIP 100 5% 1/10W
R335 1-216-025-00 RES,CHIP 100 5% 1/10W
R337 1-216-065-71 RES,CHIP 4.7K 5% 1/10W
R338 1-216-049-00 RES,CHIP 1K 5% 1/10W
R401 1-216-113-00 RES,CHIP 470K 5% 1/10W
R403 1-216-041-00 RES,CHIP 470 5% 1/10W
R404 1-216-113-00 RES,CHIP 470K 5% 1/10W
R405 1-216-041-00 RES,CHIP 470 5% 1/10W
R406 1-216-113-00 RES,CHIP 470K 5% 1/10W
R408 1-216-022-00 RES,CHIP 75 5% 1/10W
R409 1-216-025-00 RES,CHIP 100 5% 1/10W
