KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
R9860 1-218-706-11 METAL CHIP 3.9K 0.50% 1/10W
R9864 1-218-701-11 METAL CHIP 2.4K 0.50% 1/10W
R9866 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9867 1-216-821-11 METAL CHIP 1K 5% 1/10W
R9868 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9869 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9882 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9884 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9885 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9886 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9887 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9888 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
R9890 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R9891 1-216-809-11 METAL CHIP 100 5% 1/10W
RESISTOR BRIDGE
RB9500 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB9510 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB9511 1-233-574-11 RES, CHIP NETWORK 10 (3216)
RB9512 1-233-574-11 RES, CHIP NETWORK 10 (3216)
RB9517 1-236-908-11 NETWORK RESISTOR(CHIP) 10K
VARISTOR
VD9500 6-500-701-01 DIODE PGB1010603NR
VD9501 6-500-701-01 DIODE PGB1010603NR
VD9502 6-500-701-01 DIODE PGB1010603NR
VD9503 6-500-701-01 DIODE PGB1010603NR
VD9504 6-500-701-01 DIODE PGB1010603NR
VD9505 6-500-701-01 DIODE PGB1010603NR
VD9506 6-500-701-01 DIODE PGB1010603NR
VD9507 6-500-701-01 DIODE PGB1010603NR
VD9518 6-500-701-01 DIODE PGB1010603NR
VD9519 6-500-701-01 DIODE PGB1010603NR
CRYSTAL
X9501 1-767-984-21 VIBRATOR, CRYSTAL
DZ
A-1101-770-A DZ BOARD, COMPLETE
(KV-34DRC430/36DRC430 L. SOUTH)
* A-1302-936-A DZ BOARD, COMPLETE
(KV-34DRC430/36DRC430 L. NORTH)
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
The high-voltage leads associated with the FBT on the DZ board are not included and
must be ordered separately. Order the following leads when requesting this DZ Board:
! 1-251-715-22 CAP ASSY, HIGH-VOLTAGE
! 1-900-805-19 WIRE ASSY, FOCUS HV
! 1-900-808-42 WIRE ASSY, G2
CAPACITOR
C5001 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C5002 1-106-383-00 MYLAR 0.047µF 10% 200V
C5003 1-162-967-11 CERAMIC CHIP 0.0033µF 10% 50V
C5004 1-106-383-00 MYLAR 0.047µF 10% 200V
C5005 1-126-235-11 ELECT 100µF 20% 16V
C5006 1-126-964-11 ELECT 10µF 20% 50V
C5007 1-126-941-11 ELECT 470µF 20% 25V
C5009 1-126-941-11 ELECT 470µF 20% 25V
C5010 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C5011 1-107-641-11 ELECT 220µF 20% 160V
C5012 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C5013 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C5014 1-164-227-11 CERAMIC CHIP 0.022µF 10% 25V
C5016 1-130-783-71 MYLAR 0.33µF 10% 100V
C5017 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C5018 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5019 1-126-968-11 ELECT 100µF 20% 50V
C5020 1-104-665-11 ELECT 100µF 20% 25V
C5022 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C5024 1-102-038-00 CERAMIC 0.001µF 500V
C5028 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C5030 1-137-365-11 MYLAR 0.0015µF 5% 50V
C5031 1-162-965-11 CERAMIC CHIP 0.0015µF 10% 50V
C5032 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C5033 1-130-495-00 MYLAR 0.1µF 5% 50V
DZ
PA
