Sony TRINITRON KV-34DRC430 - Section 7: Electrical Parts List

98
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
When ordering parts by reference
number, please include the board name.
AY
REF. NO. PART NO. DESCRIPTION VALUES
AY
* A-1073-921-A AY BOARD, COMPLETE
(KV-34DRC430 L. NORTH)
A-1101-768-A AY BOARD, COMPLETE
(KV-36DRC430 L. SOUTH)
A-1101-772-A AY BOARD, COMPLETE
(KV-34DRC430 L. SOUTH)
* A-1302-941-A AY BOARD, COMPLETE
(KV-36DRC430 L. NORTH)
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C501 1-165-529-31 MYLAR 0.22µF 10 0V
C502 1-127-798-51 CERAMIC .0047µF 20% 250V
(KV-34DRC430/36DRC430 L. SOUTH)
! C503 1-165-529-31 MYLAR 0.22µF 10 0V
C504 1-126-961-11 ELECT 2.2µF 20% 50V
C505 1-127-794-51 CERAMIC 2200pF 20% 250V
C506 1-126-971-11 ELECT 470µF 20% 50V
C507 1-126-943-11 ELECT 2200µF 20% 25V
C508 1-127-794-51 CERAMIC 2200pF 20% 250V
C510 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
! C512 1-165-530-21 MYLAR 0.47µF 10 0V
C513 1-126-961-11 ELECT 2.2µF 20% 50V
C514 1-126-960-11 ELECT 1µF 20% 50V
C515 1-126-947-11 ELECT 47µF 20% 35V
C518 1-126-967-11 ELECT 47µF 20% 50V
C528 1-126-933-11 ELECT 100µF 20% 16V
C530 1-126-941-11 ELECT 470µF 20% 25V
C536 1-126-933-11 ELECT 100µF 20% 16V
C537 1-126-941-11 ELECT 470µF 20% 25V
C540 1-126-767-11 ELECT 1000µF 20% 16V
C542 1-126-941-11 ELECT 470µF 20% 25V
C547 1-126-767-11 ELECT 1000µF 20% 16V
C548 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C549 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C550 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C551 1-126-933-11 ELECT 100µF 20% 16V
C552 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C553 1-126-767-11 ELECT 1000µF 20% 16V
C554 1-126-933-11 ELECT 100µF 20% 16V
C555 1-126-933-11 ELECT 100µF 20% 16V
C556 1-126-767-11 ELECT 1000µF 20% 16V
C558 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C559 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C560 1-126-935-11 ELECT 470µF 20% 16V
C561 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C562 1-126-964-11 ELECT 10µF 20% 50V
C563 1-126-947-11 ELECT 47µF 20% 35V
C564 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C565 1-115-156-11 CERAMIC CHIP 1µF 10V
C566 1-162-961-11 CERAMIC CHIP 330pF 10% 50V
C567 1-165-176-11 CERAMIC CHIP 0.047µF 10% 16V
C569 1-126-767-11 ELECT 1000µF 20% 16V
C574 1-126-960-11 ELECT 1µF 20% 50V
C577 1-126-960-11 ELECT 1µF 20% 50V
C578 1-126-964-11 ELECT 10µF 20% 50V
C579 1-126-957-11 ELECT 0.22µF 20% 50V
C580 1-126-957-11 ELECT 0.22µF 20% 50V
C583 1-136-161-00 FILM 0.047µF 5% 50V
C584 1-126-960-11 ELECT 1µF 20% 50V
C585 1-136-161-00 FILM 0.047µF 5% 50V
C591 1-126-935-11 ELECT 470µF 20% 16V
C593 1-126-935-11 ELECT 470µF 20% 16V
C595 1-104-666-11 ELECT 220µF 20% 25V
C597 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C598 1-130-495-00 MYLAR 0.1µF 5% 50V
C599 1-126-953-11 ELECT 2200µF 20% 35V
C601 1-164-156-11 CERAMIC CHIP 0.1µF 25V
SECTION 7: ELECTRICAL PARTS LIST
