Sony TRINITRON KV-34DRC430 - HV Service Flowchart

31
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
3-10. HV SERVICE FLOWCHART
Confirm:
- Ik Protector
Refer to P. 30
YES
Is the spare part on
P. 32 changed?
Is DZ Board
NO
Start
Which category part
on P. 32 changed?
NO
YES
Finished with HV service
Confirm:
- HV
- HV Protector
- Ik Protector
Refer to P. 29/30
Confirm:
- HV Protector
Refer to P. 29
Confirm:
- B+
Refer to P. 29
Confirm:
- HV
Refer to P. 29
Confirm:
- B+
- Hold Down
Refer to P. 29
Category A
Category B
Category C
Category D
Category E
