99
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
C607 1-130-495-00 MYLAR 0.1µF 5% 50V
C611 1-130-495-00 MYLAR 0.1µF 5% 50V
C612 1-126-953-11 ELECT 2200µF 20% 35V
C613 1-126-953-11 ELECT 2200µF 20% 35V
C900 1-126-940-11 ELECT 330µF 20% 25V
C903 1-104-666-11 ELECT 220µF 20% 25V
C909 1-136-177-00 FILM 1µF 5% 50V
C912 1-136-177-00 FILM 1µF 5% 50V
C915 1-162-959-11 CERAMIC CHIP 330pF 5% 50V
C918 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C921 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C924 1-164-677-11 CERAMIC CHIP 0.033µF 10% 16V
C927 1-128-934-91 CERAMIC CHIP 0.33µF 20% 10V
C930 1-164-388-91 CERAMIC CHIP 270pF 5% 50V
C933 1-130-495-00 MYLAR 0.1µF 5% 50V
C939 1-126-933-11 ELECT 100µF 20% 16V
C942 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C945 1-126-933-11 ELECT 100µF 20% 16V
CONNECTOR
CN501 1-695-915-11 TAB (CONTACT)
*
! CN503 1-580-843-11 PIN, CONNECTOR (POWER)
* CN504 1-766-241-11 PIN, CONNECTOR (PC BOARD) 3P
(ALL EXCEPT KV-34DRC430 L. NORTH)
* CN505 1-766-241-11 PIN, CONNECTOR (PC BOARD)
* CN506 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
* CN507 1-764-812-12 CONNECTOR, BOARD TO BOARD 11P
* CN508 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
* CN509 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
CN510 1-793-494-11 CONNECTOR, BOARD TO BOARD 40P
* CN514 1-766-240-11 PIN, CONNECTOR (PC BOARD) 2P
CN518 1-695-915-11 TAB (CONTACT)
* CN521 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
* CN524 1-564-515-11 PLUG, CONNECTOR 12P
* CN526 1-564-508-11 PLUG, CONNECTOR 5P
* CN527 1-564-511-61 PLUG, CONNECTOR 8P
* CN900 1-779-892-11 CONNECTOR, BOARD TO BOARD 10P
* CN903 1-564-506-11 PLUG, CONNECTOR 3P
DIODE
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-511-40 DIODE S1VB40
D504 8-719-991-33 DIODE 1SS133T-77
D505 8-719-991-33 DIODE 1SS133T-77
D508 8-719-991-33 DIODE 1SS133T-77
D509 8-719-991-33 DIODE 1SS133T-77
D510 8-719-991-33 DIODE 1SS133T-77
D511 8-719-991-33 DIODE 1SS133T-77
D512 8-719-991-33 DIODE 1SS133T-77
D513 8-719-991-33 DIODE 1SS133T-77
D514 8-719-991-33 DIODE 1SS133T-77
D515 8-719-991-33 DIODE 1SS133T-77
D516 8-719-991-33 DIODE 1SS133T-77
D517 8-719-991-33 DIODE 1SS133T-77
D519 8-719-991-33 DIODE 1SS133T-77
D520 8-719-991-33 DIODE 1SS133T-77
D521 8-719-991-33 DIODE 1SS133T-77
D522 8-719-991-33 DIODE 1SS133T-77
D524 8-719-991-33 DIODE 1SS133T-77
D526 8-719-991-33 DIODE 1SS133T-77
D530 8-719-924-13 DIODE MTZJ-T-77-22B
D531 8-719-924-13 DIODE MTZJ-T-77-22B
D534 8-719-991-33 DIODE 1SS133T-77
D535 8-719-991-33 DIODE 1SS133T-77
D540 8-719-991-33 DIODE 1SS133T-77
D541 8-719-991-33 DIODE 1SS133T-77
D548 8-719-991-33 DIODE 1SS133T-77
D900 8-719-110-31 DIODE RD12ESB2
D903 8-719-110-31 DIODE RD12ESB2
FUSE
! F501 1-532-506-51 FUSE 6.3A 250V
FERRITE BEAD
FB500 1-412-911-11 FERRITE 0µH
(KV-34DRC430/36DRC430 L. NORTH)
FB501 1-412-911-11 FERRITE 0µH
(KV-34DRC430/36DRC430 L. SOUTH)
FB502 1-412-911-11 FERRITE 0µH
FUSE HOLDER
! FH501 1-533-223-11 FUSE HOLDER 0A 0V
! FH502 1-533-223-11 FUSE HOLDER 0A 0V
AY
