Sony TRINITRON KV-34DRC430 - Page 100

100
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
IC
IC501 8-759-450-47 IC BA05T
IC502 8-759-520-49 IC PQ30RV21
IC504 6-700-898-01 IC PQ05RD21SSJH
IC505 8-759-653-07 IC PQ09RD21SSJH
IC508 8-759-246-70 IC TA8216H
IC900 8-749-016-08 IC STK390-910
IC903 8-759-595-52 IC CXA8070AP
CHIP CONDUCTOR
JR501 1-216-864-11 SHORT CHIP
JR502 1-216-864-11 SHORT CHIP
JR509 1-216-864-11 SHORT CHIP
JR510 1-216-864-11 SHORT CHIP
JR511 1-216-864-11 SHORT CHIP
JR512 1-216-864-11 SHORT CHIP
JR513 1-216-864-11 SHORT CHIP
JR514 1-216-864-11 SHORT CHIP
JR515 1-216-864-11 SHORT CHIP
JR516 1-216-864-11 SHORT CHIP
COIL
L502 1-412-525-31 INDUCTOR 10µH
L505 1-469-320-21 INDUCTOR 100µH
L506 1-469-320-21 INDUCTOR 100µH
L507 1-469-317-21 INDUCTOR 10µH
L508 1-412-529-11 INDUCTOR 22µH
! L510 1-433-404-21 TRANSFORMER, LINE FILTER
(KV-34DRC430/36DRC430 L. NORTH)
! L510 1-433-900-11 TRANSFORMER, LINE FILTER
(KV-34DRC430/36DRC430 L. SOUTH)
! L511 1-433-404-21 TRANSFORMER, LINE FILTER
L900 1-408-612-31 INDUCTOR 56µH
IC LINK
PS502 1-532-984-11 IC LINK 2A 50V
TRANSISTOR
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-600-22 TRANSISTOR 2SA1235-F
Q503 8-729-600-22 TRANSISTOR 2SA1235-F
Q505 8-729-600-22 TRANSISTOR 2SA1235-F
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-600-22 TRANSISTOR 2SA1235-F
Q510 8-729-600-22 TRANSISTOR 2SA1235-F
Q511 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q512 8-729-600-22 TRANSISTOR 2SA1235-F
Q513 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q514 8-729-600-22 TRANSISTOR 2SA1235-F
Q517 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q518 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q519 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q524 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q527 8-729-600-22 TRANSISTOR 2SA1235-F
RESISTOR
R501 1-216-864-11 SHORT CHIP
R502 1-244-207-11 WIREWOUND 3.3K 5% 10W
(KV-34DRC430/36DRC430 L. SOUTH)
R503 1-205-997-11 CEMENT 2.2K 5% 10W
(KV-36DRC430 L. SOUTH)
R503 1-244-207-11 CEMENT 3.3K 5% 10W
(KV-34DRC430 L. SOUTH)
R504 1-216-833-11 METAL CHIP 10K 5% 1/10W
R505 1-216-833-11 METAL CHIP 10K 5% 1/10W
R506 1-216-857-11 METAL CHIP 1M 5% 1/10W
R507 1-247-895-91 CARBON 470K 5% 1/4W
R508 1-218-265-11 METAL 8.2M 5% 1W
(KV-34DRC430/36DRC430 L. SOUTH)
R508 1-219-512-11 METAL 2.2M 5% 1/2W
(KV-34DRC430/36DRC430 L. NORTH)
! R509 1-244-268-11 CEMENTED 1 5% 20W
(KV-34DRC430/36DRC430 L. SOUTH)
! R509 1-244-270-11 CEMENTED 0.47 5% 20W
(KV-34DRC430/36DRC430 L. NORTH)
! R510 1-244-268-11 CEMENTED 1 5% 20W
(KV-34DRC430/36DRC430 L. SOUTH)
! R510 1-244-270-11 CEMENTED 0.47 5% 20W
(KV-34DRC430/36DRC430 L. NORTH)
R511 1-216-849-11 METAL CHIP 220K 5% 1/10W
R512 1-216-849-11 METAL CHIP 220K 5% 1/10W
R513 1-216-833-11 METAL CHIP 10K 5% 1/10W
R515 1-216-833-11 METAL CHIP 10K 5% 1/10W
R516 1-216-857-11 METAL CHIP 1M 5% 1/10W
