Sony TRINITRON KV-34DRC430 - Page 101

101
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R527 1-216-341-11 METAL OXIDE 0.22 5% 1W
R531 1-216-821-11 METAL CHIP 1K 5% 1/10W
R532 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R533 1-216-833-11 METAL CHIP 10K 5% 1/10W
R534 1-218-716-11 METAL CHIP 10K 0.50% 1/10W
R535 1-218-722-11 METAL CHIP 18K 0.50% 1/10W
R536 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R537 1-218-750-11 METAL CHIP 270K 0.50% 1/10W
R539 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R540 1-216-821-11 METAL CHIP 1K 5% 1/10W
R542 1-216-821-11 METAL CHIP 1K 5% 1/10W
R544 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R545 1-216-805-11 METAL CHIP 47 5% 1/10W
R546 1-216-805-11 METAL CHIP 47 5% 1/10W
R547 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R548 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R550 1-216-845-11 METAL CHIP 100K 5% 1/10W
R551 1-216-833-11 METAL CHIP 10K 5% 1/10W
R552 1-216-837-11 METAL CHIP 22K 5% 1/10W
R553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R554 1-216-864-11 SHORT CHIP
R555 1-216-833-11 METAL CHIP 10K 5% 1/10W
R556 1-216-839-11 METAL CHIP 33K 5% 1/10W
R557 1-216-821-11 METAL CHIP 1K 5% 1/10W
R558 1-216-857-11 METAL CHIP 1M 5% 1/10W
R559 1-216-847-11 METAL CHIP 150K 5% 1/10W
R560 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R563 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R565 1-216-821-11 METAL CHIP 1K 5% 1/10W
R570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R572 1-216-809-11 METAL CHIP 100 5% 1/10W
R573 1-216-847-11 METAL CHIP 150K 5% 1/10W
R574 1-216-809-11 METAL CHIP 100 5% 1/10W
R577 1-216-821-11 METAL CHIP 1K 5% 1/10W
R579 1-216-821-11 METAL CHIP 1K 5% 1/10W
R581 1-216-864-11 SHORT CHIP
R582 1-216-864-11 SHORT CHIP
R585 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R586 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R588 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R589 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R591 1-216-821-11 METAL CHIP 1K 5% 1/10W
R595 1-216-813-11 METAL CHIP 220 5% 1/10W
R596 1-216-833-11 METAL CHIP 10K 5% 1/10W
R598 1-216-833-11 METAL CHIP 10K 5% 1/10W
R599 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R601 1-216-813-11 METAL CHIP 220 5% 1/10W
R602 1-216-833-11 METAL CHIP 10K 5% 1/10W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R606 1-216-833-11 METAL CHIP 10K 5% 1/10W
R607 1-216-833-11 METAL CHIP 10K 5% 1/10W
R610 1-216-821-11 METAL CHIP 1K 5% 1/10W
R611 1-216-833-11 METAL CHIP 10K 5% 1/10W
R617 1-249-385-11 CARBON 2.2 5% 1/4W
R622 1-249-385-11 CARBON 2.2 5% 1/4W
R631 1-249-429-11 CARBON 10K 5% 1/4W
R632 1-249-429-11 CARBON 10K 5% 1/4W
R635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R636 1-216-833-11 METAL CHIP 10K 5% 1/10W
R643 1-216-864-11 SHORT CHIP
R646 1-216-864-11 SHORT CHIP
R900 1-216-864-11 SHORT CHIP
R903 1-260-288-11 CARBON 0.47 5% 1/2W
R906 1-260-288-11 CARBON 0.47 5% 1/2W
R909 1-216-843-11 METAL CHIP 68K 5% 1/10W
R912 1-216-381-11 METAL OXIDE 0.22 5% 3W
R915 1-215-886-11 METAL OXIDE 100 5% 2W
R918 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R920 1-216-864-11 SHORT CHIP
R921 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R927 1-218-696-11 METAL CHIP 1.5K 0.50% 1/10W
R930 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R933 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R939 1-216-805-11 METAL CHIP 47 5% 1/10W
R942 1-216-429-00 METAL OXIDE 270 5% 1W
R945 1-216-805-11 METAL CHIP 47 5% 1/10W
R948 1-216-845-11 METAL CHIP 100K 5% 1/10W
R949 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R950 1-218-708-11 METAL CHIP 4.7K 0.50% 1/10W
R951 1-216-845-11 METAL CHIP 100K 5% 1/10W
R954 1-216-821-11 METAL CHIP 1K 5% 1/10W
RELAY
! RY501 1-755-389-11 RELAY (AC POWER)
AY
