Sony TRINITRON KV-34DRC430 - Page 102

102
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
TRANSFORMER
T502 1-437-697-11 TRANSFORMER, STANDBY
(KV-34DRC430/36DRC430 L. NORTH)
T502 1-437-742-11 TRANSFORMER, STANDBY
(KV-34DRC430/36DRC430 L. SOUTH)
THERMISTOR
! TH501 1-803-540-11 THERMISTOR, POSITIVE
(KV-34DRC430/36DRC430 L. SOUTH)
! TH501 1-803-970-11 THERMISTOR, POSITIVE
(KV-34DRC430/36DRC430 L. NORTH)
TUNER
TU502 8-598-593-70 TUNER, FSS BTF-WA421
VARISTOR
! VD501 1-804-992-21 VARISTOR
(KV-34DRC430/36DRC430 L. NORTH)
! VD501 1-804-995-11 VARISTOR
(KV-34DRC430/36DRC430 L. SOUTH)
PA
* A-1085-903-A PA BOARD, COMPLETE
The P and PA Boards are interchangeable.
Either board can be used as a replacement.
Due to the complexity of this board, performing component level fi eld
repairs is not recommended. If service is required, complete board
replacement is the preferred repair method.
Data is provided for reference only.
CAPACITOR
C9507 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C9508 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9509 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9510 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C9511 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9513 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9514 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9515 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9516 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9517 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9519 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9521 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C9523 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C9524 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9525 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9526 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9527 1-164-505-11 CERAMIC CHIP 2.2µF 16V
C9528 1-126-246-11 ELECT CHIP 220µF 20% 4V
C9529 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9530 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9531 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9532 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9533 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9534 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9535 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9537 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9538 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C9540 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9541 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9542 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9543 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9545 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9546 1-164-230-11 CERAMIC CHIP 220pF 5% 50V
C9547 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9549 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9550 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9551 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9552 1-126-246-11 ELECT CHIP 220µF 20% 4V
C9553 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C9554 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9555 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9557 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9558 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9559 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9560 1-126-246-11 ELECT CHIP 220µF 20% 4V
C9561 1-100-756-91 CERAMIC CHIP 0.047µF 0V
C9562 1-127-692-11 CERAMIC CHIP 10µF 10% 16V
C9563 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9566 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9570 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9571 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9575 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C9576 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9578 1-162-916-11 CERAMIC CHIP 12pF 5% 50V
PAAY
