Sony TRINITRON KV-34DRC430 - Page 103

103
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C9579 1-162-916-11 CERAMIC CHIP 12pF 5% 50V
C9583 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9584 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9585 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9586 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9587 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9588 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9589 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9623 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9824 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C9825 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C9826 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C9828 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9830 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9831 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9832 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9833 1-100-566-91 CERAMIC CHIP 0.1µF 10% 25V
C9835 1-100-588-21 ELECT CHIP 1000µF 20% 6.3V
C9836 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9839 1-126-394-11 ELECT CHIP 10µF 20% 16V
C9841 1-100-118-21 ELECT CHIP 82µF 20% 16V
C9842 1-137-897-21 ELECT CHIP 150µF 20% 4V
C9843 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
CONNECTOR
* CN9500 1-818-400-11 HDMI CONNECTOR
CN9504 1-564-593-11 PLUG, CONNECTOR 14P
DIODE
D9500 8-719-210-39 DIODE EC10QS-04
D9501 6-500-294-01 DIODE PTZ-TE25-3.9B
D9502 8-719-977-28 DIODE DTZ10B
D9503 8-719-977-28 DIODE DTZ10B
D9506 8-719-404-50 DIODE MA111-TX
D9507 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB9504 1-414-235-22 FERRITE 0µH
FB9505 1-414-235-22 FERRITE 0µH
FB9506 1-414-235-22 FERRITE 0µH
FB9507 1-414-235-22 FERRITE 0µH
FB9508 1-414-235-22 FERRITE 0µH
FB9509 1-414-235-22 FERRITE 0µH
FB9510 1-414-235-22 FERRITE 0µH
FB9512 1-414-235-22 FERRITE 0µH
FILTER
* FL9501 1-813-308-11 INDUCTOR 0µH
* FL9504 1-813-308-11 INDUCTOR 0µH
* FL9505 1-813-308-11 INDUCTOR 0µH
* FL9506 1-813-308-11 INDUCTOR 0µH
IC
IC9500 6-706-257-01 IC FMS6418AM16X
IC9502 6-704-819-01 IC CS4335-KSZR
IC9503 6-704-407-01 IC PQ1CZ41H2ZPH
IC9504 6-704-001-01 IC BR24L02F-WE2
IC9505 6-704-499-01 IC SII9993CTG100
IC9506 6-703-042-01 IC CD4052BNSR
IC9509 6-550-014-01 TRANSISTOR SSM6N15FU(TE85R)
IC9514 8-759-331-71 IC NJM4558E(TE2)
IC9517 6-804-888-01 IC MB89965CpFV1-G-120E1
IC9521 8-759-642-22 IC UPC29M05T-E2
JACK
J9503 1-794-623-11 JACK, PIN 2P
COIL
L9501 1-416-948-21 INDUCTOR 10µH
L9502 1-400-303-21 INDUCTOR 68µH
IC LINK
PS9500 1-576-415-21 FUSE 2A 32V
TRANSISTOR
Q9501 8-729-024-88 TRANSISTOR MUN2212T1
Q9502 8-729-421-22 TRANSISTOR UN2211
Q9503 8-729-027-62 TRANSISTOR DTC144WKA-T146
Q9506 8-729-024-88 TRANSISTOR MUN2212T1
Q9511 8-729-421-22 TRANSISTOR UN2211
