Sony TRINITRON KV-34DRC430 - Page 109

109
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
IC
IC5001 8-759-701-01 IC NJM2904M
IC5002 8-759-700-07 IC NJM2903M
IC5004 8-759-696-71 IC STV9379A
IC5005 8-759-803-42 IC LA6500-FA
IC5006 8-749-013-76 IC PQ6RD83B
IC5007 8-759-981-61 IC LM2901M
IC5502 8-759-981-61 IC LM2901M
IC5504 8-759-803-42 IC LA6500-FA
IC5506 8-759-803-42 IC LA6500-FA
IC5511 8-759-701-01 IC NJM2904M
IC5512 8-759-929-65 IC LM7912CT
IC5515 8-759-701-01 IC NJM2904M
IC6501 6-705-810-01 IC MCZ3001DB
IC6502 6-700-897-01 IC PQ12RD21SSJH
IC6503 8-749-012-13 IC DM-58
IC6505 8-749-921-86 IC SE-140N
IC8001 8-759-700-07 IC NJM2903M
IC8002 6-705-810-01 IC MCZ3001DB
IC8004 8-759-701-01 IC NJM2904M
! IC8005 6-706-127-01 IC TL1431ACZ-AP
IC8006 8-759-700-07 IC NJM2903M
! IC8104 6-706-127-01 IC TL1431ACZ-AP
CHIP CONDUCTOR
JR5000 1-216-864-11 SHORT CHIP
JR5001 1-216-864-11 SHORT CHIP
JR5002 1-216-864-11 SHORT CHIP
JR5003 1-216-864-11 SHORT CHIP
JR5004 1-216-864-11 SHORT CHIP
JR5005 1-216-864-11 SHORT CHIP
JR5006 1-216-864-11 SHORT CHIP
JR5007 1-216-864-11 SHORT CHIP
JR5008 1-216-864-11 SHORT CHIP
JR5009 1-216-864-11 SHORT CHIP
JR5010 1-216-864-11 SHORT CHIP
JR5011 1-216-864-11 SHORT CHIP
JR5012 1-216-864-11 SHORT CHIP
JR5013 1-216-864-11 SHORT CHIP
JR5014 1-216-864-11 SHORT CHIP
JR5015 1-216-864-11 SHORT CHIP
JR5016 1-216-864-11 SHORT CHIP
JR5065 1-216-864-11 SHORT CHIP
JR5501 1-216-864-11 SHORT CHIP
JR5504 1-216-864-11 SHORT CHIP
JR5505 1-216-864-11 SHORT CHIP
JR8000 1-216-864-11 SHORT CHIP
JR8001 1-216-864-11 SHORT CHIP
JR8002 1-216-864-11 SHORT CHIP
JR8003 1-216-864-11 SHORT CHIP
JR8005 1-216-864-11 SHORT CHIP
JR8006 1-216-864-11 SHORT CHIP
JR8007 1-216-864-11 SHORT CHIP
JR8022 1-216-864-11 SHORT CHIP
JR8023 1-216-864-11 SHORT CHIP
COIL
L5001 1-406-665-11 INDUCTOR 100µH
L5003 1-406-892-31 INDUCTOR 4MH
L5005 1-424-874-11 COIL, HORIZONTAL LINEARITY
L5504 1-406-989-21 INDUCTOR 10MH
L5505 1-406-989-21 INDUCTOR 10MH
L6501 1-412-525-31 INDUCTOR 10µH
L6502 1-412-525-31 INDUCTOR 10µH
L6503 1-412-525-31 INDUCTOR 10µH
L6505 1-406-665-11 INDUCTOR 100µH
L6506 1-412-525-31 INDUCTOR 10µH
L6507 1-412-525-31 INDUCTOR 10µH
L6510 1-412-523-41 INDUCTOR 6.8µH
L6511 1-412-523-41 INDUCTOR 6.8µH
L6514 1-412-525-31 INDUCTOR 10µH
L6517 1-412-521-31 INDUCTOR 4.7µH
L6518 1-412-521-31 INDUCTOR 4.7µH
L8002 1-428-950-31 INDUCTOR 125µH
L8005 1-406-674-11 INDUCTOR 3.3MH
PHOTO COUPLER
PH6501 8-749-016-81 PHOTO COUPLER PC123Y22
PH6502 8-749-016-81 PHOTO COUPLER PC123Y22
PH8001 8-749-016-81 PHOTO COUPLER PC123Y22
PH8003 8-749-016-81 PHOTO COUPLER PC123Y22
PH8004 8-749-016-81 PHOTO COUPLER PC123Y22
DZ
