Sony TRINITRON KV-34DRC430 - Page 115

115
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
RELAY
! RY6501 1-755-395-11 RELAY (AC POWER)
! RY6502 1-755-389-11 RELAY (AC POWER)
SPARK GAP
SG8002 1-517-499-21 GAP, SPARK
TRANSFORMER
T5001 1-437-669-11 TRANSFORMER, HORIZONTAL OUTPUT
T5002 1-435-636-21 TRANSFORMER, HORIZONTAL DRIVE
T6502 1-437-696-31 TRANSFORMER, CONVERTER
! T8001 1-453-464-11 FBT ASSY, NX-6200//X4J4
T8003 1-437-664-11 TRANSFORMER, DYNAMIC FOCUS
THERMISTOR
TH5002 1-807-796-11 THERMISTOR
MY
* A-1302-937-A MY BOARD, COMPLETE
Due to the complexity of this board, performing component level fi eld
repairs is not recommended. If service is required, complete board
replacement is the preferred repair method.
Data is provided for reference only.
CAPACITOR
C2017 1-126-964-11 ELECT 10µF 20% 50V
C2019 1-126-964-11 ELECT 10µF 20% 50V
C2020 1-126-964-11 ELECT 10µF 20% 50V
C2022 1-126-964-11 ELECT 10µF 20% 50V
C2027 1-126-964-11 ELECT 10µF 20% 50V
C2029 1-126-964-11 ELECT 10µF 20% 50V
C2038 1-162-916-11 CERAMIC CHIP 12pF 5% 50V
C2039 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2040 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2041 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2042 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2043 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2044 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C2045 1-126-933-11 ELECT 100µF 20% 16V
C2046 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2050 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2058 1-126-963-11 ELECT 4.7µF 20% 50V
C2059 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2060 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2061 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2062 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2064 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2065 1-126-933-11 ELECT 100µF 20% 16V
C2066 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2067 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C2069 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2071 1-126-963-11 ELECT 4.7µF 20% 50V
C2072 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2075 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2077 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2082 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2085 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2088 1-216-864-11 SHORT CHIP
C2089 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2090 1-216-864-11 SHORT CHIP
C2091 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
C2096 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2097 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2098 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C2099 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C2100 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2103 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2106 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2107 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2108 1-126-933-11 ELECT 100µF 20% 16V
C2109 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C2110 1-162-919-11 CERAMIC CHIP 22pF 5% 50V
C2115 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2116 1-126-933-11 ELECT 100µF 20% 16V
C2117 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2122 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2123 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C2124 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2126 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2130 1-126-933-11 ELECT 100µF 20% 16V
C2131 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2132 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2200 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2201 1-164-156-11 CERAMIC CHIP 0.1µF 25V
MYDZ
