Sony TRINITRON KV-34DRC430 - Page 117

117
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C2506 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2508 1-126-933-11 ELECT 100µF 20% 16V
C2510 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C2512 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2513 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2514 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2515 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2516 1-126-933-11 ELECT 100µF 20% 16V
C2517 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2518 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2519 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2520 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C2521 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C2522 1-126-947-11 ELECT 47µF 20% 35V
C2523 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2524 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2525 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2527 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2528 1-162-962-11 CERAMIC CHIP 470pF 10% 50V
C2530 1-126-947-11 ELECT 47µF 20% 35V
C2532 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2533 1-162-960-11 CERAMIC CHIP 220pF 10% 50V
C2534 1-126-947-11 ELECT 47µF 20% 35V
C2535 1-162-962-11 CERAMIC CHIP 470pF 10% 50V
C2536 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2538 1-126-947-11 ELECT 47µF 20% 35V
C2539 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2540 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C2541 1-162-915-11 CERAMIC CHIP 10pF 0.50pF 50V
C2542 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2543 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2544 1-126-963-11 ELECT 4.7µF 20% 50V
C2545 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2546 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2548 1-126-947-11 ELECT 47µF 20% 35V
C2549 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2550 1-126-963-11 ELECT 4.7µF 20% 50V
C2551 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2553 1-126-947-11 ELECT 47µF 20% 35V
C2554 1-126-947-11 ELECT 47µF 20% 35V
C2558 1-126-963-11 ELECT 4.7µF 20% 50V
C2559 1-126-933-11 ELECT 100µF 20% 16V
C2560 1-126-947-11 ELECT 47µF 20% 35V
C2561 1-126-963-11 ELECT 4.7µF 20% 50V
C2563 1-126-961-11 ELECT 2.2µF 20% 50V
C2564 1-126-961-11 ELECT 2.2µF 20% 50V
C2565 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C2566 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2569 1-126-961-11 ELECT 2.2µF 20% 50V
C2570 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2571 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2572 1-126-960-11 ELECT 1µF 20% 50V
C2574 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2575 1-126-960-11 ELECT 1µF 20% 50V
C2579 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2582 1-126-933-11 ELECT 100µF 20% 16V
C2584 1-126-933-11 ELECT 100µF 20% 16V
C2585 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2586 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C2587 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C2588 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
CONNECTOR
CN2006 1-793-174-11 SOCKET,PC CONNECTOR (PC BOARD)
* CN2301 1-764-333-11 PIN, CONNECTOR(PCB)(V TYPE) 10P
* CN2304 1-564-595-11 PLUG, CONNECTOR 14P
CN2305 1-770-721-11 CONNECTOR, BOARD TO BOARD 4P
DIODE
D2310 8-719-083-57 DIODE UDZSTE-173.6B
D2500 8-719-404-50 DIODE MA111-TX
D2501 8-719-404-50 DIODE MA111-TX
D2502 8-719-404-50 DIODE MA111-TX
D2503 8-719-404-50 DIODE MA111-TX
D2504 8-719-404-50 DIODE MA111-TX
D2505 8-719-978-33 DIODE DTZ-TT11-6.8B
D2506 8-719-978-33 DIODE DTZ-TT11-6.8B
D2507 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB2200 1-414-229-11 FERRITE 0µH
FB2501 1-216-864-11 SHORT CHIP
FB2503 1-216-864-11 SHORT CHIP
FB2504 1-216-864-11 SHORT CHIP
FB2505 1-414-229-11 FERRITE 0µH
