129
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
RESISTOR BRIDGE
RB9500 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB9510 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB9511 1-233-574-11 RES, CHIP NETWORK 10 (3216)
RB9512 1-233-574-11 RES, CHIP NETWORK 10 (3216)
RB9516 1-236-908-11 NETWORK RESISTOR(CHIP) 10K
RB9517 1-236-908-11 NETWORK RESISTOR(CHIP) 10K
VARISTOR
VD9500 6-500-701-01 DIODE PGB1010603NR
VD9501 6-500-701-01 DIODE PGB1010603NR
VD9502 6-500-701-01 DIODE PGB1010603NR
VD9503 6-500-701-01 DIODE PGB1010603NR
VD9504 6-500-701-01 DIODE PGB1010603NR
VD9505 6-500-701-01 DIODE PGB1010603NR
VD9506 6-500-701-01 DIODE PGB1010603NR
VD9507 6-500-701-01 DIODE PGB1010603NR
VD9518 6-500-701-01 DIODE PGB1010603NR
VD9519 6-500-701-01 DIODE PGB1010603NR
CRYSTAL
X9501 1-767-984-21 VIBRATOR, CRYSTAL
BY
* A-1302-940-A BY BOARD, COMPLETE
Due to the complexity of this board, performing component level fi eld
repairs is not recommended. If service is required, complete board
replacement is the preferred repair method.
Data is provided for reference only.
CAPACITOR
C2801 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2802 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2804 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C2805 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2806 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2808 1-128-996-11 ELECT CHIP 4.7µF 20% 50V
C2809 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2810 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2811 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2812 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2813 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2814 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2815 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2816 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2817 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2818 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C2819 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2820 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2821 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2822 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2823 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2824 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2825 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C2826 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2827 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2828 1-110-563-11 CERAMIC CHIP 0.068µF 10% 16V
C2829 1-162-968-11 CERAMIC CHIP 0.0047µF 10% 50V
C2830 1-128-996-11 ELECT CHIP 4.7µF 20% 50V
C2831 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2833 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2834 1-125-891-11 CERAMIC CHIP 0.47µF 10% 10V
C2835 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C2836 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2837 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2840 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2841 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2842 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2843 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C2844 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2845 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2846 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C2847 1-127-715-91 CERAMIC CHIP 0.22µF 10% 16V
C2849 1-162-966-11 CERAMIC CHIP 0.0022µF 10% 50V
C2850 1-117-681-11 ELECT CHIP 100µF 20% 16V
C2851 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3001 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C3002 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C3003 1-128-453-21 ELECT CHIP 47µF 20% 6.3V
C3005 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3006 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3008 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3009 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3011 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3012 1-164-156-11 CERAMIC CHIP 0.1µF 25V
BY
P
