Sony TRINITRON KV-34DRC430 - Page 132

132
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C3495 1-124-779-00 ELECT CHIP 10µF 20% 16V
C3496 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3499 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3500 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C3501 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3613 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C3614 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3615 1-124-779-00 ELECT CHIP 10µF 20% 16V
C3617 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C3618 1-127-760-11 CERAMIC CHIP 4.7µF 10% 6.3V
C3619 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C3622 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3623 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3624 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C3906 1-126-204-11 ELECT CHIP 47µF 20% 16V
C3912 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
CONNECTOR
* CN2803 1-564-509-11 PLUG, CONNECTOR 6P
* CN2805 1-764-334-11 PIN, CONNECTOR(PCB)(V TYPE) 11P
DIODE
D2803 8-719-404-50 DIODE MA111-TX
D2806 8-719-069-55 DIODE UDZSTE-175.6B
D3001 8-719-404-50 DIODE MA111-TX
D3002 8-719-083-58 DIODE UDZSTE-173.9B
D3089 8-719-800-76 DIODE 1SS226
D3090 8-719-800-76 DIODE 1SS226
D3401 8-719-914-43 DIODE DAN202K
D3402 8-719-914-44 DIODE DAP202K
D3403 8-719-978-33 DIODE DTZ-TT11-6.8B
D3404 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB3001 1-500-451-11 FERRITE 0µH
FB3002 1-216-864-11 SHORT CHIP
FB3303 1-216-809-11 METAL CHIP 100 5% 1/10W
FB3304 1-469-110-21 FERRITE 0µH
FB3401 1-414-235-22 FERRITE 0µH
FB3402 1-414-235-22 FERRITE 0µH
FB3403 1-216-864-11 SHORT CHIP
FB3624 1-216-864-11 SHORT CHIP
FILTER
FL3001 1-234-177-21 FERRITE 0µH
FL3002 1-234-177-21 FERRITE 0µH
FL3003 1-781-924-21 FILTER, LOW PASS (SMD)
FL3301 1-234-558-21 FILTER, LOW PASS
FL3302 1-234-557-21 FILTER, LOW PASS
FL3303 1-234-557-21 FILTER, LOW PASS
FL3401 1-781-923-21 FILTER, LOW PASS (SMD)
IC
IC2801 8-752-102-68 IC CXA2170Q
IC3002 8-759-583-47 IC UPC2933T-E2
IC3003 6-701-892-01 IC TC90A90F(BH,DRY)
IC3004 8-759-642-22 IC UPC29M05T-E2
IC3089 6-704-573-01 IC M24C32-WMN6T(B)
IC3090 6-801-376-01 IC MB94918RpF-G-147-BND
IC3091 8-759-352-91 IC PST9143NL
IC3301 6-705-992-11 IC HY57V161610ETP-7DR
IC3302 6-700-398-01 IC UPC2918T-E1
IC3303 8-752-409-78 IC CXD2095AQ
IC3306 8-759-669-78 IC TLC2933IPWR-12
IC3401 6-700-399-01 IC UPC2925T-E1
IC3402 6-702-318-01 IC W986432DH-6
IC3403 8-759-460-29 IC PST9120NL
IC3404 8-759-669-75 IC TLC2932IPWR
IC3405 8-759-453-97 IC TC7SET08FU(TE85R)
IC3406 8-759-453-97 IC TC7SET08FU(TE85R)
IC3407 8-759-453-97 IC TC7SET08FU(TE85R)
IC3408 8-759-672-57 IC CXD9509AQ
IC3409 8-759-833-72 IC NJM2870F25-TE2
IC3410 8-752-409-20 IC CXD2309AQ
IC3411 8-759-082-57 IC TC7W04FU
IC3413 8-759-549-07 IC SN74LV157APWR
IC3414 8-759-548-56 IC M52055FP
IC3608 8-759-669-75 IC TLC2932IPWR
COIL
L2801 1-469-555-21 INDUCTOR 10µH
L2803 1-469-555-21 INDUCTOR 10µH
L2804 1-469-555-21 INDUCTOR 10µH
L2805 1-469-555-21 INDUCTOR 10µH
L2806 1-469-555-21 INDUCTOR 10µH
BY
