15
B Peak indicator
Lights up when the signal is 3 dB below the level at which
d
istortion begins as a warning of excessive input level.
C Transmitter power warning
indicator
Displays an icon when the re
maining battery capacity of
the transmitter being received is almost discharged.
• The icon is not displayed if the receive signal level is
lo
w.
• This function is enabled only whe
n the transmitter is a
UTX-B40/M40/P40.
D Transmitter muting status indicato
r
Displays an icon when the
muting function of the
transmitter being received is on.
• The icon is not displayed if the receive signal level is
lo
w.
• This function is enabled only whe
n the transmitter is a
UTX-B40/M40/P40.
E Battery level indicator
Displays the battery level. “USB” is displayed when
power is supplied from the USB connector. “MI” is
displayed when power is supplied from an SMAD-P5
(option).
For details, see “Battery level indicator” (page 19).
F RF (radio
frequency input) level meter
Displays the RF input level. The number of lights will
change depending on the input level.
6 lights: 60 dBµ or higher
5 lights: 50 dBµ to 60 dBµ
4 lights: 40 dBµ to 50 dBµ
3 lights: 30 dBµ to 40 dBµ
2 lights: 20 dBµ to 30 dBµ
1 light: 10 dBµ to 20 dBµ
No lights: 10 dBµ or lower
G Me
nu display section
Displays various functions. Press the + or – button to
switc
h functions.
For details, see “Configuration menu” (page 31).
i NFC SYNC (NFC communication) button
Press to start a channel scan and for NFC communication
with the
transmitter.
For details, see “Operation” (page 23).
j SET button
Adjusts displayed function settings and enters the
displayed v
alue.
Holding down the SET button while turning on the power
t
urns the transmitter on without transmitting a signal
(transmission stopped mode).
k POWER button
Turns the power on/off.
l OUTPUT
(audio output) connector (3.5-mm
diameter, 3-pole locking mini jack, balanced
output)
Connect one end of the suppli
ed XLR-BMP conversion
output cable for the URX-P40/URX-P41D or the stereo
mini plug-BMP conversion cable for the URX-P40 here
and the other end to the microphone input on a camcorder,
mixer, or amplifier. If the microphone input connector on
the connected device is a stereo mini jack, connect the
straight (BMP) plug to the tuner and the L-shaped (stereo
mini) plug to the microphone input connector on the
device.
• To prevent damaging the tuner, do not apply a voltage
to
this connector from a microphone external power
supply (MIC+48V) or other source.
• Connection to a plug-in power microphone input
co
nnector is supported using the stereo mini plug-BMP
conversion cable for the URX-P40.
• When the SMAD-P5 (option) is connecte
d, connecting
the stereo mini plug-BMP conversion cable for the
URX-P40 to a camcorder microphone input may cause
noise to occur. In that case, use the supplied shoe mount
adaptor.
• When the stereo mini plug-BMP conversion cable for
t
he URX-P40 is connected, the output becomes
unbalanced.
m Auxiliary connector
Refer to the SMAD-P5
(option) operating instructions for
details about attaching to this unit.
n USB conn
ector (USB Type-C)
Connect to a commercially available USB portable power
supply.
When the power is turned on, the unit operates with
power supplied by the USB portable power supply.
Notes
Notes
Function Operation
Supply ON Press button for one second or
lo
nger
Supply OFF Press button until the indicator turns
off
Notes
