Sony VPL-FX52 - B Board Removal

1-6
VPL-FX52/FX52L
1-2-8. B Board Removal
* To remove the B board, remove the C board beforehand.
1 Two screws
(+PSW 4x10)
2 Disconnect the two cords.
3 Remove the B block assy
in the direction of the arrow A.
6 Two screws
(+PSW 3x8)
4 Two screws
(+PSW 3x8)
8 B board
7 B block holder
5 B sheet
CN3011
CN3001
A
