Sony VPL-FX52 - HIGH Mode of INPUT-C Computer; LOW Mode of VIDEO; HIGH Mode of VIDEO

2-10
VPL-FX52/FX52L
2-5-2. HIGH Mode of INPUT-C Computer
1. Input the 50 IRE flat field XGA60 signal to the
INPUT-C connector, and set the GAIN and BIAS for
the white balance HIGH mode to the following values.
GAIN BIAS
RED 140 85
GREEN 140 85
BLUE 140 85
2. Measure the chromaticity (x, y) at the center of the
screen.
3. Adjust the GAIN R and GAIN B in the HIGH mode of
W/B until the chromaticity (x, y) becomes (0.293,
0.310).
4. SAVE.
2-5-3. LOW Mode of VIDEO
1. Input the NTSC or PAL 50 IRE flat field component
signal to the INPUT-C connector, and set the GAIN
and BIAS for the white balance LOW mode to the
following values.
GAIN BIAS
RED 140 85
GREEN 140 85
BLUE 140 85
2. Measure the chromaticity (x, y) at the center of the
screen.
3. Adjust the GAIN R and GAIN B in the LOW mode of
W/B until the chromaticity (x, y) becomes (0.313,
0.330).
4. SAVE.
2-5-4. HIGH Mode of VIDEO
1. Input the NTSC or PAL 50 IRE flat field component
signal to the INPUT-C connector, and set the GAIN
and BIAS for the white balance HIGH mode to the
following values.
GAIN BIAS
RED 140 85
GREEN 140 85
BLUE 140 85
2. Measure the chromaticity (x, y) at the center of the
screen.
3. Adjust the GAIN R and GAIN B in the HIGH mode of
W/B until the chromaticity (x, y) becomes (0.293,
0.310).
4. SAVE.
