2-4. Service Know-How
2-4-1. When the Prism Block is Replaced
1. Perform the V COM adjustment. (Refer to Section “2-
2. VCOM Adjustment”.)
2. Write the GAMMA data of the prism block.
3. Perform the white balance adjustment. (Refer to
Section “2-5. White Balance Adjustment”.)
2-4-2. When the Board is Replaced
When the C Board is Replaced
1. Install IC3207 of the C board before replacement, into
the new C board.
2. Enter the Factory Mode.
3. Perform the V COM adjustment. (Refer to Section “2-
2. VCOM Adjustment”.)
4. If the white balance is significantly poor, perform the
white balance adjustment. . (Refer to Section “2-5.
White Balance Adjustment”.)
When the QA, QB, or B Board is Replaced
1. If the white balance is significantly poor, perform the
white balance adjustment. . (Refer to Section “2-5.
White Balance Adjustment”.)
2-5. White Balance Adjustment
Preparation before adjustment
1. Input the 100 IRE flat field XGA60 signal to the
INPUT-C connector and allow the warm-up of 10
minutes aging at a minimum.
2. Enter the Service Mode.
Press the keys in the following order.
[ENTER] → [ENTER] → ↑ → ↓ → [ENTER].
The message [Do you want to enter the Service Mode?
Yes : ↑ No : ↓] appears.
Select [Yes : ↑].
[Supplementary information: How to Exit the
Service Mode]
Perform the step 2 KEY operation.
The message [Do you want to return to the User Mode?
Yes : ↑ No : ↓] appears.
Select [Yes : ↑].
2-5-1. LOW Mode of INPUT-C Computer
1. Input the 100 IRE flat field XGA60 signal to the
INPUT-C connector, and set the GAIN and BIAS for
the white balance LOW mode to the following values,
then SAVE.
GAIN BIAS
RED 160 85
GREEN 140 85
BLUE 160 85
