Sony VPL-FX52 - Disassembly; Top Cabinet Assy Removal

1-2
VPL-FX52/FX52L
1 Loosen the two screws.
(Special screw M4)
5 Top cabinet assy
2 Remove the lens cover assy
in the direction of the arrow.
Two claws
Three claws
3 Screw
(+B 4x10)
4 Six screws
(+B 4x10)
CN2200
1-2. Disassembly
1-2-1. Top Cabinet Assy Removal
