Sony VPL-FX52 - Extension Boards and Extension Cables

1-10
VPL-FX52/FX52L
XF32 board x 3
Flat cable 24P
X702 x 12
Flat cable 32P
XF32 x 3
Cable 2P
XC-C x 1
Cable 3P
XC-C x 1
Cable 4P
XC-C x 1
Cable 7P
XC-C x 1
Cable 11P
XC-C x 1
Cable 50P
XC-C x 1
X702 board x 4XC board x 1
1
2
3
4
5
6
Cable 6P
B-QB x 1
9
Cable 9P
B-QB x 1
0
7
8
X KIT ASSY (A-1159-856-A)
1-2-15. Extension Boards and Extension Cables
n
The numbers of the extension cables and those of the figure correspond each other. (Refer to 1-2-16)
