Sony VPL-HS60 - Page 59

4-5
VPL-HS60/HS51A
Lamp Power Supply Block
301
302
303
304
304
304
304
305
306
A
A
B
C
C
See Optics Block 1, 2
B
BTP
3 x 12
BTP
3 x 12
BVTP
3 x 20
No. Part No. SP Description
301 ! 1-468-866-11 s LAMP POWER SUPPLY BLOCK
302 1-543-993-11 s CORE, FERRITE
303 ! 1-787-149-11 s D.C. FAN (SIROCCO)
304 4-089-523-01 s SPRING, LAMP
305 4-089-560-02 s LENS, CONCAVE
7-685-548-19 s SCREW +BTP 3X12 TYPE2 N-S
7-685-651-79 s SCREW +BVTP 3X20 TYPE2 IT-3
