Figure 1: Pressio® ICP monitoring kit, parenchymal with bolt (Model PSO-PB).
Pressio® intracranial pressure measurement catheter
Drill bit with adjustable stop and Allen wrench Bolt for the introduction and xation
of the Pressio® sensor
Guide stylet
Figure 2: Pressio® ICP & ICT monitoring kit, parenchymal with bolt (Model PSO-PBT).
Pressio® intracranial pressure and temperature
measurement catheter
Drill bit with adjustable stop and Allen wrench Bolt for the introduction and xation
of the Pressio® sensor
Guide stylet
1000 mm
ø1.2 mm ø0.7 mm
40 mm
ø2.7 mm
1000 mm
ø1.2 mm ø0.7 mm
40 mm
ø2.7 mm
